WEIDMULLER 1942920000 PCB Connector
The SC pin header features a perpendicular plug orientation relative to the PCB, available in closed and screw flange variants. It is designed for efficient THT soldering, with a 3.81mm pitch, and supports a 10-pole configuration with 180° outgoing elbow for easy access. Made from durable PA GF with tinned copper contact surfaces, it ensures reliable electrical conduction. Suitable for industrial automation and control systems, it offers high surge voltage and current ratings, compliant with UL and IEC standards, and withstands operating temperatures from -50°C to 120°C.
WEIDMULLER 1942920000 PCB Connector Specifications:
- Pitch: 3.81 mm (0.15 inch)
- Number of poles: 10
- Solder pin length: 3.2 mm
- Pole dimensions: d= 1.0 mm, octagonal
- Solder eyelet diameter: 1.2 mm
- Material: PA GF, orange color
- Contact material: Copper alloy, tinned surface
- Rated voltage: 300V (UL), 320V (IEC)
- Rated current: 8A (UL), 17.5A (IEC at 20°C)
- Operating temperature: -50°C to 120°C
- Storage temperature: -25°C to 55°C
- Flammability: UL 94 V-0
- Protection class: Touch-safe, IP20
- Number of solder pins per pole: 1
- Plugging cycles: 25
- Certifications: UL, IEC
- Color: Orange (RAL 2000)
Buy the Weidmuller Series BC/SC 3.81 PCB Connector: 1942920000
Order the Weidmueller Series BC/SC 3.81 PCB connector today to ensure reliable industrial wiring. Featuring a 3.81mm pitch, 10 poles, THT soldering, durable insulation, and high current ratings, this high-quality connector compatible with UL and IEC standards offers excellent performance for automation and control systems. Secure your order now and benefit from quick delivery, superior build quality, and versatile application capabilities in industrial environments.
Buy Weidmueller Series BC/SC 3.81 connector with 10 poles and reliable THT soldering now and experience unmatched quality and performance.
Frequently Asked Questions
Where can I buy WEIDMULLER 1942920000?
You can click on the BUY or RFQ button to purchase 1942920000 from an authorized WEIDMULLER distributor.
How do I troubleshoot issues or seek technical support for part 1942920000?
You can download the 1942920000 datasheet or visit the WEIDMULLER website for support.
Who is the manufacturer of 1942920000?
WEIDMULLER
