WEIDMULLER 2439940000 PCB Header Connector
The OMNIMATE Signal series SL.2.50/05/180G is a male header designed for wave soldering applications. It features a 2.50 mm pitch, straight plugging direction, and a closed housing variant, making it suitable for PCB mounting. With five poles, tin-plated copper alloy contacts, and a compact 14.4 mm width, this connector supports high reliability in industrial and electronics assemblies. It complies with IEC, UL, and CSA standards, offering maximum rated voltages of 320V and currents of 6A, ensuring safe and durable connections in demanding environments.
WEIDMULLER 2439940000 PCB Header Connector Specifications:
- Pitch: 2.50 mm
- Poles: 5
- Housing: Closed (G)
- Contact Material: Copper alloy, tinned
- Contact Surface: Tinned, matte finish
- Pin Dimensions: 0.8x0.8 mm
- Solder Pin Length: 3.2 mm (+0.17 / -0.1 mm)
- Eyelet Hole Diameter: 1.3 mm
- Dimensions: Width 14.4 mm, Height 13.3 mm, Depth 8.1 mm
- Operating Temperature: -40°C to +105°C
- Rated Voltage IEC: 320V, UL: 150V, CSA: 150V
- Rated Current IEC/UL/CSA: 6A / 5A
- Number of Solder Pins: 5
- Number of Poles: 5
- Solder Eyelet Hole Diameter Tolerance: +0.1 mm
- Protection Class: IP00
- Material: PA 66 Black
- Flammability Rating: UL 94 V0
- Certifications: IEC, UL, CSA
- Touch-safe Protection: DIN VDE 0470
- Number of Plug-In Cycles: 25
Buy the Weidmueller Series SL.2.50 PCB Header: 2439940000
Order the Weidmueller Series SL.2.50 PCB header with 5 poles for secure, reliable PCB connections. Designed for wave soldering, it features tin-plated copper contacts, compact dimensions, and certified standards for safety and durability. Ideal for industrial electronics and automation systems, this connector ensures high performance in demanding environments. Purchase online today and enhance your PCB assembly with quality, ease of installation, and long-lasting connection stability. Trust Weidmueller for your electronic component needs.
Buy Weidmueller Series SL.2.50 PCB header with 5 poles for reliable PCB connections and seamless wave soldering now and experience unmatched durability and performance.
