WEIDMULLER 2617910000 Industrial Relay Module
The TERMSERIES relay module features a compact design with a 1CO contact made of AgNi, rated for 16A at 24V control voltage, suitable for various automation and control applications. It includes multiple protective circuits such as free-wheel diode and RC elements, and offers push-in actuation for easy installation. Its dimensions are 12.8 mm width, 89.4 mm height, and 87.8 mm depth, with a maximum operating temperature of 60°C and an operating temperature range of -40°C to 60°C. The relay's maximum switching voltage is 250 VAC/DC with a continuous current capacity of 16A, making it ideal for industrial control systems.
WEIDMULLER 2617910000 Industrial Relay Module Specifications:
- Width: 12.8 mm, Height: 89.4 mm, Depth: 87.8 mm
- Control Voltage: 24 V UC +10%, Rated Current AC: 16 mA, DC: 14 mA
- Rated Switching Voltage: 250 VAC/DC, Continuous Current: 16A
- Pollution Severity Level: 2, Protection Degree: IP20
- Operating Temperature: -40°C to 60°C, Storage Temperature: -40°C to 85°C
- Dielectric Strength: 4 kV for open contact, Creepage and Clearance: 25.5 mm
- Pull-in Voltage: 18.9V DC, Drop-out Voltage: 6.8V DC, Max Switching Frequency: 0.1 Hz
- Mechanical Life: 30 x 10^6 cycles, UL and EN approval standards compliant
Buy the Weidmueller Series TRP 24VUC 1CO 16A
Purchase the reliable Weidmueller Series TRP 24VUC 1CO 16A relay online today. Its robust design, high current capacity, and comprehensive protective circuits make it an ideal choice for automation systems. With a compact form factor of 12.8 mm width and high-quality AgNi contacts rated for 16A at 24V control voltage, this relay ensures durability and performance in demanding industrial environments. Easily integrate it into your control panels and optimize your operational efficiency today.
Order your Weidmueller Series TRP 24VUC 1CO 16A relay today and ensure reliable automation control for your industrial projects.
