WEIDMULLER 7760056088 4 Contact Relay
The Weidmueller DRM570024L is a compact relay designed for industrial automation, featuring 4 CO contact outputs with AgNi contact material and rated control voltage of 24V DC. It supports a maximum switching voltage of 250 VAC and a continuous current of 5A. Its robust, plug-in design ensures easy installation and maintenance. The relay includes a green LED status indicator, a test button optional for testing, and an integrated free-wheel diode option. Its compact dimensions and high capacity make it ideal for control panels requiring reliable switching and switching capacity up to 1250 VA resistive load.
WEIDMULLER 7760056088 4 Contact Relay Specifications:
- Width: 21 mm (0.827 inch)
- Height: 27.4 mm (1.079 inch)
- Depth: 35.7 mm (1.406 inch)
- Net weight: 33.9239 g
- Rated control voltage: 24 V DC
- Rated current: 37.8 mA
- Power rating: 0.9 W
- Switching voltage: 250 VAC
- Max switching current: 5 A
- Inrush current: 10 A/50 ms
- Contact resistance: <50 mΩ
- Mechanical life: 20 x 10^6 cycles
- Ambient temperature: -40°C to +60°C
- Standard compliance: IEC 61810-1, UL 508
- Protection degree: IP20
- Dielectric strength: 1.8 kV between input-output
Buy the Weidmueller Series DRM: 4 CO Relay: DRM570024L
Order the Weidmueller DRM570024L online today to benefit from a compact, high-capacity relay designed for industrial automation. It features four changeover contacts, a control voltage of 24V DC, and an integrated LED indicator for real-time status monitoring. This relay supports a maximum switching voltage of 250V AC and a current capacity of 5A, making it ideal for controlling voltage loads with durability and efficiency. Its plug-in design ensures quick installation and easy maintenance in control panels or automation systems.
Buy Weidmueller DRM570024L now and experience unmatched reliability and performance for industrial automation applications.
