XP POWER EML30US36E Medical Power Supply
The EML30 series comprises open frame and encapsulated AC-DC power supplies designed for medical applications, offering flexible mounting options including PCB mount, open frame, chassis, and DIN rail. Compliant with global safety standards, the supplies meet Class B emission limits for conducted and radiated noise, and support peak load capability of 130% for 30 seconds. They provide a compact size and reliable performance, making them suitable for healthcare devices, industrial power management, and system integration requiring high efficiency, robust isolation, and regulatory compliance.
XP POWER EML30US36E Medical Power Supply Specifications:
- Input Voltage Range: 85-264 VAC
- Input Frequency: 47-63 Hz
- Efficiency: 79-88%
- Operating Temperature: -20°C to +70°C, derates above +50°C
- Output Voltages: 3.3V to 48VDC
- Output Power: 20W to 30W
- Output Current: 6.00A (3.3V), 7.80A (5V), 3.33A (9V), 2.50A (12V), 2.00A (15V), 1.25A (24V), 0.83A (36V), 0.62A (48V)
- Peak Load Capability: 130% for 30 seconds
- Isolation Rating: 4000 VAC input to output
- Protection: Overvoltage, overload, short circuit with restart
- Standards: EN60601-1, ANSI/AAMI ES60601-1, IEC60601-1
- Dimensions: 75.2 x 34.6 x 26.7 mm (Open Frame), 87.9 x 34.6 x 25.4 mm (Encapsulated), 78.7 x 38.1 x 27.9 mm (Other models), with mounting options including PCB, chassis, DIN rail
- Weight: approximately 0.35 to 0.37 lbs depending on configuration
- Cooling Method: Convection-cooled
- Vibration and Shock Resistance: Standard testing per IEC 68-2-6 and IEC 68-2-27
- Certifications: UL, CE, CB, safety and EMC standards compliance
Buy the Velo 30W Series – Reliable Medical Power Supplies for Industrial Applications
Enhance your healthcare or industrial system with Velo medical power supplies—compact, reliable, and compliance-ready AC-DC units. Designed for optimal performance, these supplies feature flexible mounting options including PCB, chassis, open frame, and DIN rail, supporting peak loads of 130% for 30 seconds. They meet stringent safety standards such as UL and IEC60601‑1, ensuring safety and EMI compliance. Perfect for medical devices, industrial automation, and power management, purchase online today for seamless integration and dependable power solutions with fast delivery and technical support.
Buy Velo 30W power supplies now and experience unmatched reliability and performance in medical and industrial environments.
Frequently Asked Questions
Where can I buy XP POWER EML30US36E?
You can click on the BUY or RFQ button to purchase EML30US36E from an authorized XP POWER distributor.
How do I troubleshoot issues or seek technical support for part EML30US36E?
You can download the EML30US36E datasheet or visit the XP POWER website for support.
Who is the manufacturer of EML30US36E?
XP POWER
