XP POWER ITP0348D12 industrial DC-DC converter
The ITP series is a compact 3W DC-DC power module designed for industrial applications, offering cost-effective and reliable performance. It features regulated single and dual outputs ranging from 3.3V to 15V DC, with a wide input voltage range of 4.5V to 75V DC in various configurations. The ultra-compact SIP6 package provides 1.6kV DC input/output isolation and high efficiency. It is compliant with EN55032 standards and includes short-circuit protection and remote On/Off (for single output models). The module operates reliably in temperatures from -40°C to +75°C, with full power available up to +70°C.
XP POWER ITP0348D12 industrial DC-DC converter Specifications:
- Power: 3 Watts
- Input Voltage Range: 4.5V to 75V DC
- Output Voltage: 3.3V, 5.0V, 12.0V, 15.0V, ±5V, ±12V, ±15V
- Output Current: Up to 700 mA depending on model
- Input/Output Isolation: 1.6kV DC
- Efficiency: Up to 84%
- Operating Temperature: -40°C to +75°C
- Full Power Operation: Up to +70°C
- Package: SIP6 ultra-compact
- Protection: Short-circuit, overcurrent
- Remote On/Off: Yes (single output models)
- Compliance: EN55032
- MTBF: >0.95 million hours (MIL-HDBK-217F, +25°C)
- Warranty: 3 years
Buy the XP Power Series DC-DC Converter: ITP0348D12
Purchase the XP Power ITP0348D12 online today for a reliable 3W industrial DC-DC converter featuring regulated outputs from 3.3V to 15V. Designed for applications requiring wide input voltages and high efficiency, it comes with UL, CE, and EN55032 compliance. The module offers 1.6kV DC isolation, operates from -40°C to +75°C, and includes short-circuit protection plus remote On/Off control. Ideal for demanding industrial environments, this compact module ensures optimal performance and durability with a 3-year warranty and high MTBF.
Buy XP Power ITP0348D12 now and experience unmatched reliability and performance with high efficiency in a compact design.
Frequently Asked Questions
Where can I buy XP POWER ITP0348D12?
You can click on the BUY or RFQ button to purchase ITP0348D12 from an authorized XP POWER distributor.
How do I troubleshoot issues or seek technical support for part ITP0348D12?
You can download the ITP0348D12 datasheet or visit the XP POWER website for support.
Who is the manufacturer of ITP0348D12?
XP POWER
