XP POWER ITP0348D15 DC-DC Converter
The ITP series provides a compact 3W DC-DC converter module designed for cost-effective industrial applications. It features a wide input voltage range from 4.5V to 75V DC, regulated single and dual outputs from 3.3V to 15V, high efficiency, and 1% output regulation. Encased in an ultra-compact SIP6 package, it offers 1.6kVDC isolation, remote On/Off (single output), and operates in temperatures from -40°C to +75°C, with full power to +70°C. Meets EN55032 standards, includes short-circuit protection, and is suitable for robust, space-constrained designs.
XP POWER ITP0348D15 DC-DC Converter Specifications:
- Input Voltage Range: 4.5V to 75V DC (various models for 4.5-18V, 9-36V, 18-75V)
- Output Voltage: 3.3V, 5V, 12V, 15V (regulated, single & dual outputs)
- Power: 3 Watts
- Isolation: 1.6kVDC between input and output
- Efficiency: Up to 84%
- Operating Temperature: -40°C to +75°C, full power up to +70°C
- Package: SIP6 ultra-compact form factor, dimensions approximately 17.0 x 10.1 x 11.7 mm
- Remote On/Off: Supported on single output models
- Standards: EN55032 compliance, UL62368-1, CE LVD
- Protection: Short-circuit, overcurrent, thermal shutdown
Buy the Buy XP Power ITP Series 3W DC-DC Converter Part Number ITP0348D15 Online
Purchase the XP Power ITP0348D15 series 3W DC-DC converter online today and enjoy fast delivery, reliable performance, and excellent regulation for your industrial applications. Designed with wide input voltage ranges from 4.5V to 75V DC, these modules offer high efficiency and 1% output regulation, ensuring stable power in space-constrained environments. With robust encapsulation, 1.6kVDC isolation, remote On/Off support, and compliance with EN55032 standards, these compact units are ideal for demanding industrial power supply solutions. Make your project more efficient and reliable now.
Order your XP Power ITP0348D15 series 3W DC-DC converter today and ensure reliable power regulation for your industrial projects.
Frequently Asked Questions
Where can I buy XP POWER ITP0348D15?
You can click on the BUY or RFQ button to purchase ITP0348D15 from an authorized XP POWER distributor.
How do I troubleshoot issues or seek technical support for part ITP0348D15?
You can download the ITP0348D15 datasheet or visit the XP POWER website for support.
Who is the manufacturer of ITP0348D15?
XP POWER
