XP POWER JTE0624S05 Power Supply Module
The JTE series power supply offers a compact, high-efficiency design suitable for various industrial applications. It features a 4:1 input range with operating temperatures from -40°C to +100°C, providing reliable performance in harsh environments. With a DIP-24 plastic case and optional metal case, it delivers up to 6 Watts of power with an isolation voltage of 1500 VDC, supporting both single and dual outputs. Designed for safety and EMC compliance, it features overload, short circuit protection, and excellent noise filtering for stable operation.
XP POWER JTE0624S05 Power Supply Module Specifications:
- Input Voltage Range: 9-36 VDC (24V models), 18-75 VDC (48V models)
- Input Filter: Pi network
- Input Surge: 50VDC for 100 ms (24V), 100VDC for 100 ms (48V)
- Operating Temperature: -40°C to +100°C
- Output Voltage: 5V
- Output Voltage Balance: +2% max for dual outputs
- Initial Set Accuracy: ±2%
- No minimum load required
- Line Regulation: 1.2% max
- Load Regulation: 5% max for dual, 20.5% max for 12V
- Ripple & Noise: 80 mV pk-pk, 20 MHz bandwidth
- Transient Response: 20 ms typical
- Overload Protection: Trip & restart (Hiccup mode)
- Maximum Capacitive Load: 135% - 185% of Full Load
- Efficiency: 75%-85%
- Isolation Voltage: 1500 VDC input to output, 1000 VDC input to case
- Isolation Capacitance: 1000 pF
- Switching Frequency: 330 kHz
- MTBF: >800,000 hours at 25°C
- Operating Humidity: Up to 95%, non-condensing
- EMC Emissions: EN55022 class A
- Safety Approvals: UL60950-1, CSA C22.2 No.60950-1
Buy the Buy Power Solutions JTE Series Part Number JTE0624S05 Online
Enhance your industrial setup with the reliable Power Supply Module from the JTE series. Offering a compact design, high efficiency, and wide temperature range, this power supply ensures stable operation for various equipment. With protection features like overload and short circuit protection, it provides peace of mind. Its high isolation voltage and EMI compliance make it suitable for sensitive applications. Purchase online today to secure a dependable power source that guarantees performance in tough conditions, backed by a 3-year warranty.
Buy Power Solutions JTE Series JTE0624S05 now and experience unmatched reliability and performance in demanding industrial environments.
Frequently Asked Questions
Where can I buy XP POWER JTE0624S05?
You can click on the BUY or RFQ button to purchase JTE0624S05 from an authorized XP POWER distributor.
How do I troubleshoot issues or seek technical support for part JTE0624S05?
You can download the JTE0624S05 datasheet or visit the XP POWER website for support.
Who is the manufacturer of JTE0624S05?
XP POWER
