XP POWER JTF1524S12 Power Conversion Module
This high power density module features a wide 4:1 input voltage range and operates efficiently with up to 90% efficiency. It is designed with a durable metal case and provides 1600 VDC isolation. The device supports a standard remote on/off function and operates reliably within a temperature range of -40°C to +105°C.
XP POWER JTF1524S12 Power Conversion Module Specifications:
- Input Voltage Range: 24 (9-36 VDC), 48 V (18-75 VDC)
- Input Current: See table
- Ripple & Noise: 85 mV pk-pk, 20 MHz bandwidth for JTF 8, 10, 12; 60 mV pk-pk for JTF 15
- Output Voltage: 3.3 V, 5 V, 12 V, 15 V, and others with various typical values
- Maximum Capacitive Load: 150% of full load for JTFO8 & JTF 15, 170% for JTF10 & JTF12
- Efficiency: Up to 90%
- Isolation Voltage: 1600 VDC Input to Output
- Operating Temperature: -40°C to +85°C (derate at +60°C to +105°C)
- Case Temperature: +105°C max
- Humidity: Up to 90%, non-condensing
- Cooling: Natural convection
- Safety Approvals: UL60950-1, UL62368-1
Buy the Buy High Power Density Module Part Number JTF1524S12 Online
Discover the convenience of purchasing this high power density power conversion module online. It features a broad 4:1 input voltage range, high efficiency up to 90%, and robust 1600 VDC isolation, ensuring dependable operation across a wide temperature range of -40°C to +105°C. Its compact metal case and remote on/off capability make installation and integration straightforward, making it ideal for industrial, automation, and critical electronic applications. Buy now to enhance your system’s performance and reliability effortlessly.
Buy high power density module JTF1524S12 now and experience unmatched reliability and performance with wide input range and high efficiency.
Frequently Asked Questions
Where can I buy XP POWER JTF1524S12?
You can click on the BUY or RFQ button to purchase JTF1524S12 from an authorized XP POWER distributor.
How do I troubleshoot issues or seek technical support for part JTF1524S12?
You can download the JTF1524S12 datasheet or visit the XP POWER website for support.
Who is the manufacturer of JTF1524S12?
XP POWER
