XP POWER ECL15US12S industrial power supply
The ECL15 series is a compact, 15-watt AC-DC power supply suitable for industrial applications. It features open frame PCB, chassis, and encapsulated options, with high efficiency and low no-load power consumption below 0.3 W. Models provide various output voltages including 5V, 12V, 15V, 24V, and 48V, with peak load capability of 130%. They meet UL, EN, and CSA standards, offering high reliability with MTBF over 400,000 hours, suitable for rigorous industrial environments, featuring overcurrent, overvoltage, and short circuit protections, and operate efficiently from -20°C to +70°C.
XP POWER ECL15US12S industrial power supply Specifications:
- Input Voltage: 85-264 VAC, 120-370 VDC
- Input Frequency: 47-63 Hz
- Efficiency: See tables, Peak load: 130%.
- Output Voltages: 5V, 12V, 15V, 24V, 48V options
- Output Current: Varies from 0.52A to 6.50A depending on model
- Output Power: Up to 15 W
- Dimensions: Vary by mounting type, approx. 2.56 inches (65 mm) length
- Protection: Overvoltage (115-140%), Overload (120-200%), Short circuit
- Environmental: Operating temp -20°C to +70°C, Humidity up to 95%RH
- Certifications: UL, EN55022, IEC60950, CSA
- Mechanical: Open frame, encapsulated, screw terminal options available
- MTBF: Over 400,000 hours at 25°C
- Cooling: Convection cooled, suitable for industrial environments
- Safety: Meets necessary EMC, safety, and reliability standards
Buy the Reliable Power Supply 15W for Industrial Applications
Purchase the high-quality industrial power supply online today and ensure your equipment runs reliably and efficiently. With versatile mounting options, multiple output voltages, and robust protections including overcurrent and overvoltage safeguards, this 15W power supply guarantees consistent performance in harsh environments. Compact, UL listed, and designed for easy installation, it’s the ideal choice for automation, control systems, and manufacturing equipment. Order now and benefit from fast delivery and dedicated customer support to keep your operations running smoothly.
Buy the ECL15 series power supply now and experience unmatched reliability and performance in demanding industrial environments.
Frequently Asked Questions
Where can I buy XP POWER ECL15US12S?
You can click on the BUY or RFQ button to purchase ECL15US12S from an authorized XP POWER distributor.
How do I troubleshoot issues or seek technical support for part ECL15US12S?
You can download the ECL15US12S datasheet or visit the XP POWER website for support.
Who is the manufacturer of ECL15US12S?
XP POWER
