XP POWER SDS60DTLOOMKT Power Supply
The SDS60 series power supplies are compact, industry-standard 3” x 5” open frame units suitable for 1U applications. They offer single, dual, triple, and quad outputs, with voltages from 3.3 V to 48 V, featuring efficiencies of 80%, and are convection-cooled for reliable performance. These power supplies are highly versatile, with built-in protections, EMI compliance, and an MTBF of 190,000 hours, making them ideal for industrial, automation, and control system applications in regulated environments. They comply with UL/CSA safety standards and operate efficiently across wide input voltage ranges.
XP POWER SDS60DTLOOMKT Power Supply Specifications:
- Input Voltage: 90-264 VAC, 120-370 VDC
- Efficiency: 80% typical at 230 VAC full load
- Input Frequency: 47-63 Hz
- Isolation: 3000 VAC input to output, 1500 VAC input to ground
- Inrush Current: <15 A at 115 VAC, <30 A at 280 VAC
- Switching Frequency: 60 kHz typical
- Power Density: 3.5 W/in³
- Earth Leakage Current: <0.30 mA at 115 VAC
- Output Operating Temperature: 0°C to +70°C, derates from 100%
- Storage Temperature: -40°C to +85°C
- Output Voltage Tolerance: ±1% initial accuracy, +10% trim on V1
- MTBF: 190,000 hours at 25°C
- EMC & Safety: EN55022 level B, EN60950-1, UL60950-1
- Start Up Delay: 2 seconds, Hold Up Time: 12 ms min at 110 VAC
- Protection: Overvoltage (112-132%), Overload (110-150%), Short circuit, Over temperature
- Dimensions: 5.00 x 3.00 x 0.16 inches (127 x 76 x 4 mm), weight approx. 0.52 lbs
- Cooling: Convection-cooled
- Certifications: UL, CSA
Buy the Power Supply Series SDS60 Industry Standard 3x5 Power Supply: SDS60DTLOOMKT
Order the SDS60DTLOOMKT power supply online today and benefit from a compact design, high efficiency, multi-output capability, and UL safety approval. Ideal for automation, industrial, and control applications, this open frame unit ensures reliable performance with protections against overvoltage, overload, and short circuits. Enjoy quick delivery, easy ordering, and expert support to enhance your project’s power management with the SDS60 series power supplies, designed for demanding environments and long-term dependability.
Buy SDS60DTLOOMKT power supply now and enjoy reliable power delivery for industrial automation and control systems.
Frequently Asked Questions
Where can I buy XP POWER SDS60DTLOOMKT?
You can click on the BUY or RFQ button to purchase SDS60DTLOOMKT from an authorized XP POWER distributor.
How do I troubleshoot issues or seek technical support for part SDS60DTLOOMKT?
You can download the SDS60DTLOOMKT datasheet or visit the XP POWER website for support.
Who is the manufacturer of SDS60DTLOOMKT?
XP POWER
