XP POWER VCS70US05 industrial power supply
The VCS700U is a 100W industrial power supply designed for reliable, efficient operation with minimal electromagnetic interference. It features Class B emissions compliance, auto-recovery overvoltage protection, continuous restart short circuit protection, and overload protection adjustable from 110% to 150% of output. It provides output voltages from 5V to 48V, with adjustable and fixed options, and operates on 85-264 VAC via convection cooling. Suitable for power management in industrial applications, it is chassis-mounted for ease of installation and performs well from -25°C to +70°C.
XP POWER VCS70US05 industrial power supply Specifications:
- Input Voltage: 85-264 VAC, 127-370 VDC
- Input Frequency: 47-63 Hz
- Input Current: VCS50: 1.1 A, VCS70: 1.4 A, VCS100: 2.0 A
- Output Power: 50W to 100W depending on model
- Output Voltage: 5V, 12V, 15V, 24V, 48V
- Ripple & Noise: Up to 480 mV depending on voltage
- Efficiency: 79% to 88%
- Protection: Auto-recovery overvoltage, overload (110-150%), short circuit
- Operating Temperature: -25°C to +70°C
- Cooling: Convection cooled
- Isolation: 3000 VAC Input to Output
- Dimensions: M3 or M4 screw terminals, maximum screw penetration 0.157 inches
- Operating Humidity: 0-95% RH, non-condensing
- MTBF: Over 500,000 hours at 25°C
- Certifications: IEC60950-1, UL60950-1, CSA, TUV
- Switching Frequency: 65 kHz typical
- Storage Temperature: -40°C to +80°C
- Operating Altitude: Up to 3000 meters
- Shock & Vibration: Compliant with IEC standards
Buy the Green DJ Power VCS70US05 – Reliable Power Supply for Industrial Applications
Purchase the Green DJ Power VCS70US05 today online to ensure reliable power delivery for your industrial projects. This 100W power supply offers adjustable output voltages from 5V to 48V, making it versatile for various applications. Designed with high efficiency, auto-recovery protections, and convection cooling, it guarantees long-term stability in demanding environments. Its compact chassis mount and wide temperature range make installation straightforward. Order now to experience consistent operation, energy efficiency, and peace of mind in your power management solutions.
Get Green DJ Power VCS70US05 today—built for precision and long-lasting durability in industrial environments.
Frequently Asked Questions
Where can I buy XP POWER VCS70US05?
You can click on the BUY or RFQ button to purchase VCS70US05 from an authorized XP POWER distributor.
How do I troubleshoot issues or seek technical support for part VCS70US05?
You can download the VCS70US05 datasheet or visit the XP POWER website for support.
Who is the manufacturer of VCS70US05?
XP POWER
