3M BS-32-6S-NB Datasheet & Stock

The BS-32-6S-NB is a terminal, 16-14 gauge nylon-insulated block fork terminals, #6 stud. The block-style fork has longer, square sides which lie flat against terminal block barriers, locking the terminal in place. The nylon insulation provides relief from vibration that can cause the wire to fail prematurely. The nylon insulation also prevents incidental metal to metal contact that can cause shorts. Type: Spade
Stud / Tab Size: # 6
Wire Gauge: 16 AWG - 14 AWG
Termination Style: Crimp
Insulation: Insulated
Color: Blue
Contact Plating: Tin
Contact Material: Copper
Insulation Material: Nylon
Length: 21.84 mm
Material: Electrolytic (ETP) Copper
Width: 6.35 mm
