ADDA AK1861HBAT Datasheet & Stock
The AK1861HB-AT is a high-speed axial fan operating at 115VAC, featuring a 2-ball bearing design and terminal power connection. It is housed in a durable aluminum die-cast frame with black paint finish and equipped with a black PBT plastic impeller reinforced with glass fibers. The fan rotates counter-clockwise when viewed from the rotor side and utilizes a shaded pole induction motor. It complies with UL94V-0 flammability standards, operates at a maximum speed of 3,200 RPM, and functions within an ambient temperature range of -10°C to 70°C. The rated power is 59.8W, with a maximum static pressure of 0.85 inches of water. It offers an insulation resistance of 100 megaohms or more at 500VDC (measured between the lead wire and frame) and withstands a dielectric voltage of 1,500VAC for one minute based on UL507 standards.
Frequently Asked Questions
Where can I buy ADDA AK1861HBAT?
You can click on the BUY or RFQ button to purchase AK1861HBAT from an authorized ADDA distributor.
How do I troubleshoot issues or seek technical support for part AK1861HBAT?
You can download the AK1861HBAT datasheet or visit the ADDA website for support.
Who is the manufacturer of AK1861HBAT?
ADDA
