ADDA AK1861HBAW Axial Fan
The AK1861HB-AW is a high-speed axial fan designed for industrial cooling applications, operating at 115VAC with a maximum speed of 3200 RPM. It features a durable die-cast aluminum frame painted black and a glass fiber-reinforced PBT plastic impeller. Equipped with a capacitor-run shaded pole induction motor and a ball bearing for longevity, it operates within -10°C to 70°C. The fan delivers a rated power of 59.8W, maximum pressure of 0.85 inches of water, and meets UL standards, including UL94V-0 flammability and dielectric strength, ensuring safe, reliable operation in demanding environments.
ADDA AK1861HBAW Axial Fan Specifications:
- Frame: Die-cast aluminum, black painted
- Impeller: Glass fiber-reinforced PBT plastic, UL94V-0 rated
- Motor: Capacitor-run shaded pole induction with thermal protection
- Bearing Type: Ball bearing
- Operating Voltage: 115VAC
- Speed Range: Up to 3200 RPM
- Maximum Pressure: 0.85 inches of water
- Maximum airflow: 410 CFM
- Operating Temp: -10°C to 70°C
- Lead Wire: UL1015 AWG20
- Insulation Resistance: Over 100 megaohms at 500VDC
- Dielectric Strength: 1500VAC for 1 minute
- Noise Level: Measured at 1 meter from intake axis
- Flammability: UL94V-0
Buy the ACME 1861HBAW – Reliable Axial Fan for Industrial Applications
Discover the ACME 1861HBAW axial fan, built for industrial cooling needs. Featuring a durable aluminum frame, plastic impeller, and UL certification for safety and efficiency. Operating at 115VAC with a speed up to 3200 RPM, it delivers high airflow and pressure, ideal for demanding applications. The fan's ball bearing ensures long life, while thermal protection and UL standards guarantee safety and reliability. Upgrade your cooling systems today by ordering online for fast, secure delivery and dependable operation in harsh environments.
Buy ACME 1861HBAW now and experience unmatched reliability and high-performance cooling for demanding industrial environments.
Frequently Asked Questions
Where can I buy ADDA AK1861HBAW?
You can click on the BUY or RFQ button to purchase AK1861HBAW from an authorized ADDA distributor.
How do I troubleshoot issues or seek technical support for part AK1861HBAW?
You can download the AK1861HBAW datasheet or visit the ADDA website for support.
Who is the manufacturer of AK1861HBAW?
ADDA
