ALPHA ELECTRONICS MQP15K000A High-Precision SMT Resistor
The MQP series are high-precision SMT resistors featuring ultra-stable Z-Foil technology. Designed for precision applications, these molded, J-lead terminal resistors offer exceptional temperature coefficient of resistance of 0.05 ppm/°C and resistance tolerance to 0.01%. With rated power of 250 mW, they demonstrate outstanding load life stability, ensure minimal resistance change over time, and operate reliably across temperatures from -55°C to +125°C. Ideal for industrial, measurement, and automation systems requiring high accuracy and long-term stability.
ALPHA ELECTRONICS MQP15K000A High-Precision SMT Resistor Specifications:
- Resistance Tolerance: 0.01%
- Temperature Coefficient of Resistance: 0.05 ppm/°C (typical)
- Power Rating: 250 mW at 70°C
- Maximum Operating Temperature: 125°C
- Working Temperature Range: -55°C to +125°C
- Maximum Working Voltage: 100V
- Load Life Stability: to +0.005% at 70°C, 2000 hours
- Resistance Range: 50Ω to 100kΩ
- Resistance Value: expressed with significant digits (e.g., 10K, 1R2345)
- Construction: Molded with J-lead terminals, RoHS compliant
- Performance: Low TCR, high stability, suitable for precision applications
Buy the Buy Alpha Electronics MQP Series Part Number MQP15K000A Online
Order the Alpha Electronics MQP series high-precision SMT resistors online today. These resistors with ultra-stable Z-Foil technology provide resistance tolerance of 0.01%, a temperature coefficient of 0.05 ppm/°C, and a power rating of 250 mW. Fully RoHS compliant, they operate reliably from -55°C to +125°C, ensuring excellent load life stability. Perfect for industrial automation, measurement, and control systems demanding high accuracy, these resistors enhance circuit reliability and performance over long-term use.
Get Alpha Electronics MQP15K000A today—built for precision, stability, and long-lasting durability in high-performance electronic circuits.
