ALPHA ELECTRONICS MU10R0010R00BA Resistor Network
The ultra-precision SMT resistor 1-2-3 network features molded design with J-lead terminals, offering high accuracy and stability for complex electronic circuits. Designed for reliable performance, it combines precise resistance values with excellent thermal stability, making it ideal for amplifier input and feedback applications. Suitable for high-temperature environments up to 125°C, this resistor network exhibits low TCR and robust dielectric withstanding voltage ratings. Its compact dimensions and RoHS compliance cater to modern surface-mount device requirements, ensuring ease of manufacturing and long-term durability.
ALPHA ELECTRONICS MU10R0010R00BA Resistor Network Specifications:
- Type: Ultra Precision SMT Resistor 1-2-3 Network
- Configuration: Molded, J-Lead Terminal
- Resistance Range: 20Ω to 2MΩ
- Tolerance: ±0.05%, ±0.1%, ±0.5%, ±1%
- Rated Power: 0.05W to 0.5W depending on resistance
- Temperature Range: -65°C to +150°C
- Maximum Operating Temperature: 125°C
- Dielectric Withstanding Voltage: AC 200V for 1 min
- Insulation Resistance: Over 10,000 MΩ
- Resistance TCR: ±55ppm/°C to ±100ppm/°C
- RoHS Compliant
- Dimensions: L 10.2 mm, W 3.6 mm, H 1.75 mm
- Frequency Characteristic: Up to 100 MHz
- Soldering: Wave and reflow compatible with temperature peak 250°C
- Storage: Keep below 40°C and 70% RH, free from harmful gases
Buy the Buy Alpha Electronics Ultra Precision SMT Resistor 1-2-3 Network Part Number MU10R0010R00BA Online
Purchase the Alpha Electronics resistor network MU10R0010R00BA online for reliable, high-precision performance suitable for amplifier feedback and input circuits. This surface-mount device features molded construction with J-lead terminals, offering excellent thermal stability, low TCR, and robust insulation resistance. Compact and RoHS compliant, it is ideal for high-density circuit design and industrial automation. Enjoy seamless ordering, fast delivery, and quality assurance for your critical electronic projects, ensuring consistent performance in demanding environments and manufacturing processes.
Get Alpha Electronics MU10R0010R00BA today—designed for high accuracy and long-lasting stability in complex circuit applications.
Frequently Asked Questions
Where can I buy ALPHA ELECTRONICS MU10R0010R00BA?
You can click on the BUY or RFQ button to purchase MU10R0010R00BA from an authorized ALPHA ELECTRONICS distributor.
How do I troubleshoot issues or seek technical support for part MU10R0010R00BA?
You can download the MU10R0010R00BA datasheet or visit the ALPHA ELECTRONICS website for support.
Who is the manufacturer of MU10R0010R00BA?
ALPHA ELECTRONICS
