ALPHA ELECTRONICS MQP10K000A Ultra High-Precision Resistor
The MQP10K000A series consists of high-precision SMT resistors featuring Z-Foil technology, offering exceptional temperature coefficient of resistance, resistance tolerance, and stability suitable for demanding industrial and electronic applications. These molded, J-lead terminal resistors are RoHS compliant, reliable, and designed to operate at high temperatures up to 125°C with power ratings of 200 mW for MPP and 250 mW for MQP. They exhibit minimal load life variation, excellent temperature stability, and are suitable for precision circuit design, including high-frequency applications due to their frequency characteristics.
ALPHA ELECTRONICS MQP10K000A Ultra High-Precision Resistor Specifications:
- Resistance range: 55°C to +125°C operating temperature
- Maximum rated temperature: 125°C
- Tolerance: up to +0.01%
- Resistance coefficient: 0.05 ppm/°C typical (0°C to +60°C), 0.2 ppm/°C (-55°C to +125°C)
- Power rating: 200 mW (MPP), 250 mW (MQP) at +70°C
- Load life stability: to +0.005% at 70°C, 2000 hours at rated power
- Maximum working voltage: MP = 50V, MQ = 100V
- Maximum working current: 350 mA
- Temperature coefficient of resistance: 0.05 ppm/°C (typical)
- Frequency response: up to 1,000 MHz
- Insulation resistance: over 10,000 MΩ at DC 100V
- Dielectric withstand voltage: AC 200V, 1 minute
- Moisture resistance: Rated voltage, 90-98% RH, 240 hours
- Storage life: over 10,000 hours at 15°C to 35°C, 15-75% RH
- Material: Flame-retardant molded package, RoHS compliant
Buy the Alpha MQP10K000A – Reliable Ultra High-Precision SMT Resistor for Industrial Applications
Purchase Alpha MQP10K000A high-precision SMT resistor online today to ensure your circuits benefit from superior stability, minimal temperature drift, and outstanding reliability. Engineered with advanced Z-Foil technology, these resistors offer exceptional temperature coefficients, tight resistance tolerance, and excellent load life stability. Ideal for precision industrial, aerospace, and high-frequency electronic applications, they are RoHS compliant, compact, and withstand high temperatures up to 125°C. Trust in the quality and performance of Alpha’s reliable resistors to optimize your designs and reduce maintenance costs over time.
Get Alpha MQP10K000A today—built for ultra-stable precision and long-lasting durability in demanding circuits.
