ALPHA ELECTRONICS MQP30K000A High-Precision SMT Resistor
The MQP Series resistors are high-precision, RoHS-compliant surface-mount devices with ultra-stable characteristics, featuring a temperature coefficient as low as 0.05 ppm/°C and resistance tolerance of up to +0.01%. Designed with advanced Z-Foil technology, they offer excellent power ratings of 200 mW for MPP or 250 mW for MQP at +70°C, and enhanced stability over temperature and aging. Suitable for precision electronic circuits requiring high reliability, these resistors are available in various resistance values and package sizes, ensuring optimal performance in demanding industrial applications.
ALPHA ELECTRONICS MQP30K000A High-Precision SMT Resistor Specifications:
- Maximum Rated Operating Temperature: 125°C
- Working Temperature Range: 65°C to +175°C
- Maximum Working Voltage: MP = 50V, MQ = 100V
- Maximum Working Current: 350 mA
- Temperature Coefficient of Resistance (TCR): 0.05 ppm/°C (typical, 0°C to +60°C); 0.2 ppm/°C (typical, -55°C to +125°C)
- Resistance Tolerance: to +0.01%
- Rated Power: 200 mW (MPP), 250 mW (MQP) at +70°C
- Load Life Stability: to +0.005% at 70°C over 2000h at rated power
- Resistance Range: varies, specific values available upon request
- Dielectric Withstanding Voltage: AC 200V for 1 min
- Insulation Resistance: Over 10,000 MΩ at DC 100V for 1 min
- Resistance to Soldering Heat: 260°C for 10 sec
- Storage Life: 10,000 hrs at 15°C–35°C, 15–75% RH, no load
- High Temperature Exposure: 175°C for 2000 hrs
- Vibration/Shock Resistance: Meets industry standards for durability
Buy the Alpha MQP000A – Reliable Precision Resistors for Industrial Applications
Purchase the Alpha Series MQP high-precision SMT resistors online today. Engineered with advanced Z-Foil technology, these resistors offer exceptional stability, ultra-low TCR of 0.05 ppm/°C, and tight resistance tolerances up to +0.01%. Suitable for demanding industrial applications, they deliver reliable performance over extensive temperature ranges and high thermal stress. Enjoy fast delivery, extensive resistance value options, and the peace of mind that comes with top-quality components built for durability and precision in your electronic projects.
Order your Alpha Series MQP series high-precision resistors today and ensure your projects meet the highest standards of reliability and stability.
Frequently Asked Questions
Where can I buy ALPHA ELECTRONICS MQP30K000A?
You can click on the BUY or RFQ button to purchase MQP30K000A from an authorized ALPHA ELECTRONICS distributor.
How do I troubleshoot issues or seek technical support for part MQP30K000A?
You can download the MQP30K000A datasheet or visit the ALPHA ELECTRONICS website for support.
Who is the manufacturer of MQP30K000A?
ALPHA ELECTRONICS
