AMPHENOL INDUSTRIAL LPT06SE84S072LC industrial connector
Amphenol Industrial's LPT Series is a lightweight, aluminum-shell connector based on MIL-C-26482 Series I and the original PT series. It features a standard PT shell with a coupling nut, making it intermateable with the PT series. The connector includes three retention tines with stamped and formed crimp contacts that allow easy insertion and secure retention. It supports wire gauges from 22 AWG (0.34 mm²) to 12 AWG (3.5 mm²) and offers quick, positive coupling along with 5 key/keyway mating. Suitable for automation, process control, industrial automation, instrumentation, energy, and power applications. Available in various styles including box, jam nut, straight plug, wall mounting, and cable connecting, it ensures high resistance to shock, vibration, and harsh environments, with operating temperatures from -40°C to 125°C.
AMPHENOL INDUSTRIAL LPT06SE84S072LC industrial connector Specifications:
- Shell Material: Aluminum
- Insert Material: Plastic
- Material: Copper alloy
- Contact Plating: Tin/Nickel/Gold plated
- Termination: Crimp
- Temperature Range: -40°C to +125°C
- Ingress Protection: IP67 & IP69K when mated
- Current Rating: 7.5A (20#), 13A (16#), 23A/35A with RADSOK® (12#)
- Operating Voltage: 500V (max), 1500V (test voltage AC), 2300V (test voltage DC)
- Mating Cycles: 500
- Shell Styles: Box mounting, Jam nut, Straight plug, Wall mounting, Cable connecting
- Insert Arrangement: 22-12 AWG
Buy the Amphenol Series LPT: 22-12 AWG industrial connector - Part Number LPT06SE84S072LC
Secure your operations with the dependable Amphenol Series LPT industrial connector, supporting 22-12 AWG cables. Designed for harsh environments, it features quick coupling, multiple mounting styles, and excellent resistance to vibration and temperature extremes from -40°C to 125°C. Ideal for automation, instrumentation, power management, and energy applications. With certifications in progress including UL and TUV, this connector guarantees safety and durability. Easy to install with various shell configurations, it’s the perfect choice for rugged industrial settings requiring reliable interconnect solutions. Buy online now to enhance your system performance.
Order your Amphenol Series LPT connector today and ensure reliable, high-performance connections for your industrial automation and energy projects.
Frequently Asked Questions
Where can I buy AMPHENOL INDUSTRIAL LPT06SE84S072LC?
You can click on the BUY or RFQ button to purchase LPT06SE84S072LC from an authorized AMPHENOL INDUSTRIAL distributor.
How do I troubleshoot issues or seek technical support for part LPT06SE84S072LC?
You can download the LPT06SE84S072LC datasheet or visit the AMPHENOL INDUSTRIAL website for support.
Who is the manufacturer of LPT06SE84S072LC?
AMPHENOL INDUSTRIAL
