Advantech Automation ADAM6260B Ethernet Relay Module
The ADAM-6260-B is a versatile 4-channel relay output module supporting Modbus TCP protocol, with advanced hardware, multiple communication protocols including MQTT with TLS, SNMP, and RESTful, and cloud data updates to Azure. Designed for Ethernet control systems, it features auto-bypass for reliable communication, peer-to-peer I/O status mapping, a built-in web server, and a watchdog timer for system recovery. Connectivity includes two RJ45 ports, a 15-pin, and a 5-pin screw terminal, making it ideal for sophisticated automation and control applications.
Advantech Automation ADAM6260B Ethernet Relay Module Specifications:
- Channels: 4 relay outputs
- Protocol Support: Modbus/TCP, MQTT with TLS, SNMP, RESTful, ASCII
- Relay Contact Rating: 250 V / 5 A resistive
- Switching Voltage: Max 300 Vac (Dry/Wet Contact)
- Breakdown Voltage: 500 Vac (50/60Hz)
- Input Impedance: 5.2 kΩ (Wet Contact)
- Transition Time: 0.2 ms
- Operation Frequency: 360 operations/hour with load, 72,000 without load
- Counter Input: 3 kHz (32-bit + 1-bit overflow)
- Power Supply: 10-30 Vdc (24 Vdc standard)
- Communication Ports: 2 RJ45 Ethernet ports
- Dimensions: 70x122x27 mm
- Operating Temperature: -10°C to 70°C
- Storage Temperature: -20°C to 80°C
- Operating Humidity: 20-95% RH (non-condensing)
- Protection: TVS protection, over-voltage and reverse polarity protection
- Isolation Voltage: 2500 Vac
- Built-in web server, watchdog timer, system backup, user access control
- Supports cloud data updates to Azure, peer-to-peer control, auto-bypass for network redundancy
Buy the ADAM Series ADAM-6260-B 4-channel Relay TCP Module: ADAM6260B
Enhance your automation projects with the ADAM Series ADAM-6260-B Ethernet relay module. Supporting Modbus TCP, MQTT, SNMP, and RESTful protocols, it offers flexible connectivity, cloud data updates, peer-to-peer control, and a web server for easy management. Its advanced hardware includes auto-bypass for network reliability, built-in watchdog timer, and robust protection features. Dimensional features are compact at 70x122x27 mm, suitable for industrial environments operating between -10°C and 70°C. Ideal for industrial, building automation, and remote monitoring applications, buy online now for dependable system performance.
Order your ADAM Series ADAM-6260-B 4-channel relay TCP module today and enjoy reliable Ethernet automation with advanced features and seamless control.
Frequently Asked Questions
Where can I buy Advantech Automation ADAM6260B?
You can click on the BUY or RFQ button to purchase ADAM6260B from an authorized Advantech Automation distributor.
How do I troubleshoot issues or seek technical support for part ADAM6260B?
You can download the ADAM6260B datasheet or visit the Advantech Automation website for support.
Who is the manufacturer of ADAM6260B?
Advantech Automation
