AMPHENOL COMMUNICATIONS SOLUTIONS 2002111200016T4LF Board-to-Board Connector
The part is a 16-position, two-row, right-angle through-hole unshrouded header featuring gold-plated copper alloy contacts and a high-temperature resin housing. It adheres to the Minitek® 1.27mm pitch standard, offering a modular, board-to-board connector design. The connector is halogen-free with a standoff construction, suitable for various environments. It supports automated assembly and easy cleaning to remove soldering contaminants. Each contact has a rated current of 1A and a voltage rating of 125VAC. Ideal for industrial, medical, communications, and testing applications.
AMPHENOL COMMUNICATIONS SOLUTIONS 2002111200016T4LF Board-to-Board Connector Specifications:
- Material: High temperature resin housing, Copper Alloy contacts with gold flash or GXT finishes
- Electrical: 1A current per contact, 125VAC voltage rating, contact resistance 30 milliohms, insulation resistance 1000 Megohms minimum
- Mechanical: Durability of 100 mating cycles, mating force up to 2.2N/contact, unmating force at least 0.2N/contact
- Environmental: Temperature range -55°C to +125°C, 95% humidity at 96 hours, tested in Mixed Flowing Gas Class IIA
- Physical: 16 positions, two-row, right-angle, unshrouded header, high-temperature resin housing, modular design, halogen-free, PCB mount type, compatible with automated assembly
- Certifications: UL listed, file no. E66906
- Packaging: Tape and reel, tube, suitable for automated pick-and-place
Buy the Minitek127 2002111200016T4LF – Reliable Board-to-Board Connection for Industrial Applications
Purchase the Minitek127 board-to-board connector today and enhance your electronic designs with reliable and easy-to-assemble modular connectivity. This high-performance connector features a 1.27mm pitch, gold-plated contacts, and a halogen-free high-temperature resin housing. It supports up to 16 positions and is suitable for industrial controls, medical devices, data communication, and measuring equipment. With UL certification and compatibility with automated assembly, this connector ensures durability and efficiency in your manufacturing process. Get yours online now for superior performance.
Buy Minitek127 2002111200016T4LF now and experience unmatched reliability and performance in industrial, medical, and communication systems.
Frequently Asked Questions
Where can I buy AMPHENOL COMMUNICATIONS SOLUTIONS 2002111200016T4LF?
You can click on the BUY or RFQ button to purchase 2002111200016T4LF from an authorized AMPHENOL COMMUNICATIONS SOLUTIONS distributor.
How do I troubleshoot issues or seek technical support for part 2002111200016T4LF?
You can download the 2002111200016T4LF datasheet or visit the AMPHENOL COMMUNICATIONS SOLUTIONS website for support.
Who is the manufacturer of 2002111200016T4LF?
AMPHENOL COMMUNICATIONS SOLUTIONS
