AMPHENOL COMMUNICATIONS SOLUTIONS 72454010VLF Insulation Piercing Connector
The Quickie™ Connector System is a versatile, two-piece insulation piercing connector designed for printed wiring board-to-round conductor flat cable interconnection in low power applications. Constructed with full-hard phosphor bronze contacts and optional plastic latches, it features gold or tin plating for reliable electrical contact. The connector supports up to 60 wires, with optional strain relief and polarization features, making it suitable for efficient, secure connections in electronic and industrial systems. It adheres to military and industry standards, ensuring durability and high performance in demanding environments.
AMPHENOL COMMUNICATIONS SOLUTIONS 72454010VLF Insulation Piercing Connector Specifications:
- Material: Full-hard phosphor bronze contacts, polyester plastic parts rated UL-94V-0
- Plating: Gold per MIL-45204B or tin-lead; nickel plating per QQ-N-290
- Contact Resistance: Max 10 milliohms, 15 milliohms after environmental exposure
- Insulation Resistance: Min 50,000 megohms, 20,000 megohms after humidity exposure
- Voltage Rating: 1,000 volts RMS dielectric withstand voltage
- Current Rating: 1.0 ampere DC
- Cable Compatibility: Up to 60 wires, AWG #28 stranded or AWG #30 solid
- Mechanical: Contact separation force ≥ 25 grams, total mating force varies by configuration
- Environmental: Supports humidity, thermal shock, high temperature life, vibration, hydrogen sulfide, and salt spray tests
- Dimensions: Receptacle cable entry compatible with PVC-insulated wires, pin length 4.32/0.170 inch to 6.35/0.250 inch
- Design: Two-piece, molded header with optional latching, strain relief, and polarizing features
- Standards: MIL-M-24519, MIL-G-45204, MIL-G-45662, MIL-STD-105, UL-94V-0
- Special Features: Self-stripping contacts, polarization, optional locking mechanisms
Buy the BrandName BUS-12-082 – Reliable Quickie Connector System for Industrial Applications
Order the Quickie Connector System online today to enjoy quick, reliable connections with optional latching, strain relief, and high environmental resistance. Designed for low power applications with up to 60 wires, it features durable phosphor bronze contacts with gold or tin plating, and supports rugged testing conditions such as humidity, thermal shock, and vibration. Simplify your wiring assembly and ensure long-lasting performance by purchasing this high-quality, standards-compliant connector system from a trusted distributor today.
Buy BrandName BUS-12-082 now and experience unmatched reliability and performance in your low power wiring projects.
Frequently Asked Questions
Where can I buy AMPHENOL COMMUNICATIONS SOLUTIONS 72454010VLF?
You can click on the BUY or RFQ button to purchase 72454010VLF from an authorized AMPHENOL COMMUNICATIONS SOLUTIONS distributor.
How do I troubleshoot issues or seek technical support for part 72454010VLF?
You can download the 72454010VLF datasheet or visit the AMPHENOL COMMUNICATIONS SOLUTIONS website for support.
Who is the manufacturer of 72454010VLF?
AMPHENOL COMMUNICATIONS SOLUTIONS
