BROADCOM AEMDEL3KVW002 High Brightness LED
High brightness surface-mount red and amber LED lamps designed for outdoor signage and indicator applications. Featuring advanced optical epoxy, compatibility with industrial reflow soldering, and a typical viewing angle of 33°, these LEDs deliver superior brightness, uniformity, and easy assembly in tape and reel packaging. They are moisture-sensitive and require careful handling, storage in moisture barrier bags, and controlled soldering conditions. Suitable for monocolor signs, outdoor displays, and variable message signs, with a maximum junction temperature of 110°C and a forward current of 50 mA.
BROADCOM AEMDEL3KVW002 High Brightness LED Specifications:
- Color: Red and Amber
- Package Type: Surface-mount device (SMT)
- Viewing Angle: 33°
- Typical Wavelength: Red 618.0-630.0 nm, Amber 584.5-594.5 nm
- Forward Voltage: 1.8-2.4 V (Red and Amber, at 20 mA)
- Peak Forward Current: 100 mA
- DC Forward Current: 50 mA
- Power Dissipation: 120 mW
- Junction Temperature: Max 110°C
- Storage Temp Range: -40°C to +100°C
- Operating Temp Range: -40°C to +85°C
- Thermal Resistance: Approx. 270°C/W (junction to pin)
- Reverse Voltage: Not recommended for reverse bias
- Maximum Reflow Soldering Cycles: 2
- Moisture Sensitivity Level: MSL3
- Humid Storage: < 5% RH in sealed moisture barrier bag
- Material: AllnGaP technology, epoxy encapsulation
- Optical epoxy for outdoor performance, compatible with reflow soldering
Buy the Broadcom AEMD-EL3K – Reliable LED indicator for Industrial Applications
Experience exceptional brightness and reliability with Broadcom's High Brightness LED lamps, available in red and amber colors. Designed for outdoor signs, indicators, and variable message displays, these SMT components feature a 33° viewing angle, advanced epoxy encapsulation, and compatibility with industrial reflow soldering. Their robust construction, moisture sensitivity considerations, and thermal management ensure optimum performance in demanding environments. Order online now to secure high-quality LEDs that guarantee clear visibility, energy efficiency, and long-lasting operation for your signage and display needs.
Order your Broadcom SeriesAEMD-EL3K red and amber surface-mount LEDs today and enhance your outdoor signage projects with dependable brightness and durability.
Frequently Asked Questions
Where can I buy BROADCOM AEMDEL3KVW002?
You can click on the BUY or RFQ button to purchase AEMDEL3KVW002 from an authorized BROADCOM distributor.
How do I troubleshoot issues or seek technical support for part AEMDEL3KVW002?
You can download the AEMDEL3KVW002 datasheet or visit the BROADCOM website for support.
Who is the manufacturer of AEMDEL3KVW002?
BROADCOM
