BROADCOM HCPL788J000E Isolation Amplifier
The HCPL-788J-000E is an isolation amplifier designed for precise motor phase current sensing with integrated short-circuit and overload detection. It converts sense resistor voltage drops into an amplified output proportional to motor current, compatible with A/D converters. This device provides digital FAULT and analog ABSVAL outputs for quick fault diagnosis and load monitoring. Its high transient immunity, stable operation over -40°C to +85°C, and compliance with safety standards make it suitable for motor drives, industrial automation, data acquisition, and power control systems. Easy to implement and reliable under harsh electrical environments.
BROADCOM HCPL788J000E Isolation Amplifier Specifications:
- Output Voltage Compatibility: 0 to Vj...
- Isolation Transient Immunity: 25 kV/us
- Operating Temperature Range: -40 °C to +85 °C
- Supply Voltage Range: 4.5 V to 5.5 V
- Short Circuit Detection Response Time: 3 μs
- Absolute Overload Output: Fault indicator (FAULT) and rectified output (ABSVAL)
- Input Voltage Range: -200 mV to +256 mV (full scale)
- Input to Output Voltage Withstand: 5000 V rms for 1 min
- Insulation Voltage: 1414 V (UL, CSA)
- Package Type: SO-16
- Features: Short circuit and overload detection, high common-mode transient immunity, RoHS compliant
- Max Input Current: 20 mA
- Max Output Power Dissipation: 600 mW
- Designed for industrial motor control, power monitoring, data acquisition, and automation systems
Buy the Buy Avago HCPL788J000E Part Number HCPL-788J-000E Online
Purchase the Avago HCPL-788J-000E isolation amplifier online for accurate motor current sensing, quick short circuit fault detection, and overload protection. Its compact SO-16 package, high transient immunity, and compliance with UL and CSA standards make it ideal for industrial motor drives, power inverter systems, and process control applications. Designed to operate from a 4.5 V to 5.5 V supply, it features robust galvanic isolation, fast fault response within 3 μs, and integrated digital and analog outputs. Secure your reliable, high-performance sensing solutions with an easy online order today.
Get Avago HCPL-788J-000E today—built for precise current sensing, fast fault detection, and reliable industrial automation.
