BROADCOM ACNW3190300E High-Output Power Optocoupler
The high-performance ACNW3190 optocoupler efficiently drives power IGBTs and MOSFETs in motor control inverters and industrial power supplies. Featuring an AlGaAs LED and integrated power output stage, it offers peak output currents up to 5.0 A, a wide operating voltage of 15 to 30 V, and high insulation voltage of 1414 Vpeak. It includes UVLO protection, fast switching speeds (500 ns), and UL and CSA safety approvals, making it ideal for industrial inverter applications and motor drives requiring reliable, high-voltage isolation and efficient transistor gate driving.
BROADCOM ACNW3190300E High-Output Power Optocoupler Specifications:
- Maximum Peak Output Current: 5.0 A
- Input Voltage Range: 15 to 30 V
- Output Voltage Range: 0-11 V (low), 11-135 V (transition), 13.5-30 V (high)
- Isolation Voltage: ViorM=1414 Vpeak
- Switching Speed: Max 500 ns
- UVLO Threshold: 9.5 V to 12 V (high), 11 V to 13.5 V (low)
- Common Mode Rejection: >15 kV/μs at Vem=1500 V
- Thermal Resistance: A11=61°C/W, A12/A21≈39°C/W, A22≈55°C/W depending on PCB layout
- Operating Temperature: -40°C to 100°C
- UL Recognized: 5,000 Vrms for 1 min
- CSA Approved; IEC/EN/DIN EN 60747-5-5 compliant
- Dimensions: 8-pin wide body package, surface mount or gull wing options
- Input Reverse Voltage: 5 V
- Input Capacitance: 75 pF at 1 MHz
- Pollution Degree: 2
- Insulation Resistance: >10^11 Ω at 500 V
- Storage Temperature: -55°C to 125°C
Buy the Avago Series ACNW3190 IGBT Gate Drive: ACNW3190300E
Enhance your motor control and inverter systems with the high-performance ACNW3190 optocoupler. Designed for robust industrial applications, it provides up to 5A peak output current, wide operating voltage from 15 to 30V, and high insulation voltage of 1414 Vpeak. Its UL and CSA approvals ensure safety compliance. Fast switching speeds of 500 ns make it ideal for efficient power switching. Order online today and upgrade your power electronics with this high-quality, reliable optocoupler tailored for demanding industrial environments.
Order your Avago Series ACNW3190 IGBT Gate Drive today and ensure reliable, high-voltage isolation for industrial inverter and motor control projects.
