INFINEON IR2113PBF Power Driver Module
The IR2113PBF is a high-voltage, high-speed power MOSFET and IGBT driver featuring independent high- and low-side output channels. Utilizing proprietary HVIC and latch-immune CMOS technology, it offers ruggedized monolithic construction. The device's logic inputs are compatible with standard CMOS or LSTTL signals down to 3.3V. It includes a high pulse current buffer stage to reduce driver cross-conduction and matched propagation delays for high-frequency applications. The floating channel can drive a high-side N-channel power MOSFET or IGBT operating at voltages up to 500V or 600V. Additional features include immunity to negative transient voltages (DV/DT), under-voltage lockout for both channels, CMOS Schmitt-triggered inputs with pull-down resistors, cycle-by-cycle edge-triggered shutdown logic, and outputs that are in phase with inputs. Suitable for various applications such as industrial automation, consumer electronics, renewable energy systems, and power management.
INFINEON IR2113PBF Power Driver Module Specifications:
- Operating Voltage: Up to 600V (IR2113) and 500V (IR2110)
- Channel Type: High and low side
- Input Compatibility: CMOS, LSTTL, down to 3.3V logic
- Propagation Delay: Matched for high-frequency applications
- Features: Latch-immune CMOS technology, UV lockout, negative transient immunity
- Floating Channel: Drives N-channel MOSFET or IGBT
- Outputs: In phase with inputs, fault-tolerant with high pulse current buffer
- Temperature Range: -55°C to +150°C
- Power Dissipation: 16W (14-lead DIP), 1.25W (SOIC)
- Junction Temperature: 150°C, Storage -55°C to +150°C
- Lead Temperature (soldering, 10 sec): 300°C
- Peak Power Supply Voltage: Up to 600V
Buy the IR Series IR2113PBF High-Voltage Power Driver: IR2113PBF
Enhance your power electronics with the IR2113PBF high-voltage, high-speed MOSFET and IGBT driver. This reliable device offers independent high- and low-side channel operation, compatible with CMOS logic signals down to 3.3V. Its rugged monolithic construction provides excellent immunity to negative transients and UV lockout, making it ideal for industrial automation, renewable energy systems, and motor drives. With matched propagation delays and in-phase outputs, it ensures precise control at high frequencies, boosting your system efficiency and durability. Buy online today for superior power management solutions.
Order your IR2113PBF high-voltage power MOSFET and IGBT driver today and give your automation and power management projects the dependable high-voltage control they need.
