KEYSIGHT TECHNOLOGIES DAQM903A Actuator Switch Module
This is a 20-channel actuator and general-purpose switch module designed for the DAQ970A data acquisition system. It is used to cycle power to devices under test, control indicator and status lights, and actuate external relays and solenoids. The module can be combined with matrix and multiplexer modules to create customized switching systems. It features SPDT (Form C) latching relays rated for 300V and 1A for actuation and control. Suitable for test and measurement applications. Included with the module are the actuator unit and a certificate of calibration.
KEYSIGHT TECHNOLOGIES DAQM903A Actuator Switch Module Specifications:
- Number of channels: 20 single-pole, double-throw relays
- Relay type: SPDT (Form C) latching relays
- Maximum voltage: 300 V
- Maximum current: 1 A
- Power rating: 50 W
- Switching speed: Open/close speed 120 tests/sec
- Isolation within channels: >10 GΩ
- Contact resistance: <10 Ω
- Switching lifetime (no load): 100 million cycles
- Rated load switching: 100k cycles
- Environment: Operating at 0 to 55°C, 40-80% RH (non-condensing)
- Dimensions: Height 212.6 mm, Width 348.3 mm
- Weight: Approx. 411 g
- Safety compliance: EN 61010-1, UL 61010-1
- Connectivity: Compatible with DAQ970A mainframe
- Included accessories: Actuator unit, calibration certificate
- Suitable for: Control, switching, test automation, relays for power cycling
Buy the Keysight Series DAQ970A Actuator Switch: DAQM903A
Enhance your test system with the Keysight DAQM903A actuator and general-purpose switch module, featuring 20 channels with SPDT relays rated for 300V and 1A. It provides precise power cycling, relay control, and is ideal for automation, device testing, and relay management applications. Compact and reliable, it integrates seamlessly with the DAQ970A mainframe, offering easy connection via screw terminals, and supports long-term operation in laboratory and industrial environments. Perfect for expanding your data acquisition capabilities efficiently.
Get Keysight DAQM903A today—designed for reliable switching and control in test and measurement setups.
