KEYSIGHT TECHNOLOGIES E3649A Dual-Output Power Supply
The Keysight E3649A is a 100W dual-output power supply designed for bench testing and automated applications, providing stable, reliable power with versatile features including output terminals on front and rear, adjustable overvoltage protection, remote sensing, save and recall functions, and selectable voltage ranges. Its highly visible vacuum fluorescent display, durable handle, GPIB and RS-232 interfaces, and automatic cooling fan ensure ease of use, precision, and quiet operation. Ideal for testing, measurement, and power management in research and industrial environments, this power supply offers flexibility and dependable performance.
KEYSIGHT TECHNOLOGIES E3649A Dual-Output Power Supply Specifications:
- Maximum Power: 100 W
- Outputs: 2
- DC Output Ratings: 0 to 8V/3A or 0 to 35V/0.8A, 0 to 8V/5A or 0 to 35W/1.4A, 0 to 20V/1.5A or 0 to 60V/0.5A
- Net Weight: 9.1 kg
- Dimensions: 212.8 mm W x 133.0 mm H x 348.3 mm D
- Voltage Regulation: < 0.01% + 3 mV
- Current Regulation: < 0.01% + 250 pA
- Ripple & Noise (20 Hz to 20 MHz): Voltage < 5 mVpp / 0.5 mVrms for 8V/20V, < 8 mVpp / 1 mVrms for 35V/60V; Current < 4 mA rms
- Accuracy (12 months @ 25°C): Voltage < 0.05% + 10 mV, Current < 0.2% + 10 mA
- Transient Response: Less than 50 µsec to recover within 15 mV
- Settling Time: < 90 msec
- Overvoltage Protection (OVP): Accuracy < 0.5% + 0.5 V, Activation < 10 msec
- Temperature Coefficient: Voltage < 0.02% + 5 mV / °C, Current < 0.02% + 3 mA / °C
- Input Voltage: 100 Vac + 10%, 115 Vac + 10%, 230 Vac + 10%
- Warranty: One year
Buy the Buy Keysight E3649A Power Supply Part Number E3649A Online
Purchase the Keysight E3649A dual-output power supply online today and enjoy dependable 100W power delivery with versatile terminals, adjustable overvoltage protection, and seamless automation through GPIB and RS-232 interfaces. Its compact size and robust build make it ideal for research labs, industrial testing, and power management tasks. With easy front and rear terminal access, a clear vacuum fluorescent display, and automatic cooling, this power supply ensures precise, stable, and quiet operation. Order now for efficient and reliable performance in your testing environment.
Buy Keysight E3649A now and experience reliable dual-output power for testing and automation applications.
Frequently Asked Questions
Where can I buy KEYSIGHT TECHNOLOGIES E3649A?
You can click on the BUY or RFQ button to purchase E3649A from an authorized KEYSIGHT TECHNOLOGIES distributor.
How do I troubleshoot issues or seek technical support for part E3649A?
You can download the E3649A datasheet or visit the KEYSIGHT TECHNOLOGIES website for support.
Who is the manufacturer of E3649A?
KEYSIGHT TECHNOLOGIES
