KEYSIGHT TECHNOLOGIES N6751A DC Power Module
The Keysight N6751A is a 50V, 5A, 50W basic DC power module designed for automated test systems in research, design validation, and manufacturing. It offers programmable voltage and current, along with measurement and protection features, enabling precise control of power delivery to DUTs. Its compact, 1U form factor supports up to four modules in a rack, providing flexible configuration for basic DC power requirements. Connectivity options include GPIB, LAN, and USB, with full compliance to LXI Class C standards, ensuring fast command processing and high throughput in demanding test environments.
KEYSIGHT TECHNOLOGIES N6751A DC Power Module Specifications:
- Output Voltage: 50 V
- Output Current: 5 A
- Power Rating: 50 W
- Voltage Programming Accuracy: 0.1% + 19 mV
- Current Programming Accuracy: 0.15% + 20 mA
- Measurement Accuracy Voltage: 0.1% + 20 mV
- Measurement Accuracy Current: 0.15% + 20 mA
- Dimensions: 1U height, supports up to 4 modules in rack
- Connectivity: GPIB, LAN, USB 2.0
- Standard Compliance: LXI Class C
- Protection: Over-voltage, over-current, over-temperature protection
- Operational Environment: Indoor; -55°C to +105°C
- Weight: Approximately 1.3 kg
Buy the Keysight Series N6700 50V 5A Basic DC Power Module: N6751A
Upgrade your test system with the Keysight N6751A DC Power Module. This compact, high-performance module offers precise voltage and current control, fast response, and versatile connectivity options. Perfect for research, design validation, and manufacturing, it supports seamless integration with your automated test setup. Its robust protection features ensure safety and reliability during demanding tests. Buy online now to empower your electronic testing and power management solutions with Keysight’s trusted quality and performance.
Order your Keysight Series N6700 N6751A today and enhance your automated testing with reliable, programmable, and high-precision DC power solutions.
Frequently Asked Questions
Where can I buy KEYSIGHT TECHNOLOGIES N6751A?
You can click on the BUY or RFQ button to purchase N6751A from an authorized KEYSIGHT TECHNOLOGIES distributor.
How do I troubleshoot issues or seek technical support for part N6751A?
You can download the N6751A datasheet or visit the KEYSIGHT TECHNOLOGIES website for support.
Who is the manufacturer of N6751A?
KEYSIGHT TECHNOLOGIES
