L-COM TRG882C6G10M Shielded Data Cable
The TRG882-C6G series consists of shielded modular cables designed for reliable data transmission in industrial and telecommunication applications. These cables feature 26AWG stranded tin-plated copper conductors, aluminum/polyester foil shielding, and a gray PVC jacket rated for -25°C to +105°C. With an IP67 ingress protection rating when mated, they provide excellent moisture and UV resistance, supporting up to 2A at 30V AC/DC. The cables are individually packaged, compliant with UL94 V-0 flame ratings, and suitable for environments demanding durability and high-performance connectivity.
L-COM TRG882C6G10M Shielded Data Cable Specifications:
- Conductor: 26 AWG stranded tin-plated copper
- Shielding: Aluminum/polyester foil with drain wire
- Jacket: PVC, gray, flame rating VW-1
- Operating Temperature: -25°C to +105°C
- Nominal Voltage: 30 V AC/DC
- Maximum Current: 2A
- Ingress Protection: IP67 when mated
- Material: Molded PVC hood, PBT+GF insulator, Brass shell/nut with nickel plating, Phosphor bronze contacts with gold plating
- Length options: 0.5m to 10m, with detailed lengths of 0.5, 1, 2, 3, 5, and 10 meters
- Dimensions: Outer diameter approximately 0.205 inches (5.20 mm), overall length tolerance ±1 inch
Buy the L-COM Series TRG882 C6G: Shielded 26AWG Data Cable
Order the L-COM Shielded Data Cable today for reliable high-performance connectivity. Featuring 26AWG stranded copper conductors, aluminum/polyester shielding, and a durable PVC jacket, it ensures maximum protection against moisture, UV, and flame. Rated for -25°C to +105°C, supports up to 2A at 30V, and is perfect for industrial, telecom, or automation applications. Individually packaged for quality assurance, this cable guarantees robust performance and longevity in demanding environments. Buy online now for fast and secure delivery.
Get L-COM TRG882-C6G10M today—built for durability and excellent EMI shielding for industrial and telecommunication needs.
Frequently Asked Questions
Where can I buy L-COM TRG882C6G10M?
You can click on the BUY or RFQ button to purchase TRG882C6G10M from an authorized L-COM distributor.
How do I troubleshoot issues or seek technical support for part TRG882C6G10M?
You can download the TRG882C6G10M datasheet or visit the L-COM website for support.
Who is the manufacturer of TRG882C6G10M?
L-COM
