MAXIM INTEGRATED / ANALOG DEVICES MAX11192EVKIT ADC Evaluation Kit

The MAX11192EVKIT from Maxim Integrated Products is an evaluation kit designed for the MAX11192 12-bit, 2-channel, 2 Msps, fully differential successive approximation register (SAR) analog-to-digital converters (ADCs) with an internal reference. This kit includes an evaluation board and a graphical user interface (GUI) that facilitates communication between the target device and a PC via a ZedBoard equipped with a Xilinx Zynq® 7000 SoC. The connection is established through a low-pin count FMC connector to the ZedBoard, which is then connected to a PC via Ethernet. The GUI supports various sampling configurations, including adjustable sample sizes and rates, and provides real-time data visualization features such as FFT and histogram plotting. The board features integrated power supplies, including two DC-DC converters and a 5V LDO, to support operation with the ZedBoard. It is pre-installed with a MAX11192ATE+ in a 16-pin TQFN-EP package. Typical applications include current sensing in motors, encoders, LVDT measurements, programmable logic controllers, and resolvers.

View MAX11192EVKITDatasheet [pdf]

Buy the Maxim Series MAX11192: Evaluation Kit for Differential 12-bit ADC - Part MAX11192EVKIT

Enhance your development with the Maxim MAX11192 evaluation kit, featuring a high-performance 12-bit, 2-channel ADC, user-friendly GUI, and support for various sampling configurations. Perfect for industrial applications such as motor control, encoders, and sensors, this kit includes a pre-installed IC in a compact TQFN package, onboard power supplies, and seamless PC connectivity via Ethernet and FMC interface. Verify real-time data, perform FFT and histogram analysis, and optimize your system with this reliable, ready-to-use solution designed for engineers and developers seeking accurate, robust analog-to-digital conversion.

Get Maxim MAX11192EVKIT today—built for precision and long-lasting durability in industrial sensing and automation solutions.
