MAXIM INTEGRATED / ANALOG DEVICES MAX1792EUA18 Low-Dropout Linear Regulator
The MAX1792EUA18 is a low-dropout linear regulator designed for portable electronic devices, offering a guaranteed 500mA load current with low 130mV dropout. It features high-accuracy (+1%) preset voltage options of 1.8V or adjustable from 1.25V to 5.0V via external resistors. The device includes thermal shutdown, short-circuit protection, and a reset output with a 4ms delay, making it ideal for battery-powered applications like smartphones, PDAs, notebooks, and base stations. Its compact 8-pin Power-uMAX package ensures efficient thermal management and reliable performance.
MAXIM INTEGRATED / ANALOG DEVICES MAX1792EUA18 Low-Dropout Linear Regulator Specifications:
- Input Voltage: 2.5V to 5.5V
- Output Voltage: 1.8V (preset) or adjustable from 1.25V to 5.0V
- Maximum Output Current: 500mA
- Dropout Voltage: 130mV at 500mA
- Quiescent Current: 80µA (typical)
- Reset Output: Active-low, 4ms timeout
- Thermal Shutdown: 170°C
- Shutdown Current: 0.1µA
- Package: 8-pin Power-uMAX
- Operating Temperature Range: -40°C to +85°C
- Line Regulation: 0.15% to 0.2%
- Load Regulation: 0.4% to 1.0%
- Output Noise: 115µVRMS (10Hz to 1MHz)
- Fuse and short circuit protection
- Ground Pin Current: 80µA (typical), shutdown mode: 0.1µA
Buy the Maxim MAX1792U18 – Reliable Low-Dropout Linear Regulator for Industrial Applications
Purchase the MAX1792EUA18 now to ensure stable power supply in your portable devices. This reliable 500mA low-dropout linear regulator features high accuracy, thermal shutdown, and a reset output, perfect for battery-powered applications like smartphones, PDAs, notebooks, and base stations. Its compact 8-pin Power-uMAX package simplifies integration while providing excellent thermal performance. With adjustable voltage from 1.25V to 5.0V and low quiescent current, it helps optimize power efficiency. Order online now for fast delivery and dependable operation.
Buy Maxim MAX1792EUA18 now and experience unmatched reliability and performance in your portable power management designs.
