MAXIM INTEGRATED / ANALOG DEVICES MAX4761ETX High-Speed Octal Signal Switch
The MAX4761ETX+ is a high-speed octal SPDT analog switch in a compact 36-pin TQFN package. It features low input capacitance of 54pF, making it ideal for high-speed data and audio switching in USB, consumer electronics, and portable devices. Supporting a voltage range of 1.8V to 5.5V and operating from -40°C to 85°C, it boasts low on-resistance of max 3.5 ohms with flatness of 1.5 ohms, channel on-resistance matching of 0.4 ohms, and fast switching times of 45ns/25ns. Its high isolation of 80dB and crosstalk of 95dB ensure signal integrity in demanding applications.
MAXIM INTEGRATED / ANALOG DEVICES MAX4761ETX High-Speed Octal Signal Switch Specifications:
- Package: 36-pin TQFN (6mm x 6mm)
- Supply Voltage Range: 1.8V to 5.5V
- Operating Temperature: -40°C to 85°C
- Input Capacitance: 54pF (typ)
- On-Resistance: max 3.5 ohms at 25°C
- Channel On-Resistance Matching: 0.4 ohms (typ)
- On-Resistance Flatness: 1.5 ohms (typ)
- Turn-On Time: 45ns (typ)
- Turn-Off Time: 25ns (typ)
- Off Isolation: 80dB (typ)
- Crosstalk: 95dB (typ)
- Charge Injection: 15pC (typ)
- Supported standards: USB 1.1 and 2.0 Full Speed 12 Mbps
Buy the Buy MAXIM MAX4761ETX+ High-Speed Octal SPDT Signal Switch Online
Purchase the MAX4761ETX+ online today to ensure seamless data, audio, and signal switching in your consumer electronics or portable device applications. Designed for fast and reliable operation, this octal SPDT analog switch supports voltages from 1.8V to 5.5V, making it suitable for USB, audio, and high-speed data routing. The compact 36-pin TQFN package features low input capacitance, minimal charge injection, and excellent isolation and crosstalk parameters for optimal signal integrity. Take advantage of quick delivery and enhance your electronic systems with this high-performance switch now.
Buy MAXIM MAX4761ETX+ now and experience high-speed, reliable signal routing for USB and portable devices with low on-resistance and fast switching performance.
Frequently Asked Questions
Where can I buy MAXIM INTEGRATED / ANALOG DEVICES MAX4761ETX?
You can click on the BUY or RFQ button to purchase MAX4761ETX from an authorized MAXIM INTEGRATED / ANALOG DEVICES distributor.
How do I troubleshoot issues or seek technical support for part MAX4761ETX?
You can download the MAX4761ETX datasheet or visit the MAXIM INTEGRATED / ANALOG DEVICES website for support.
Who is the manufacturer of MAX4761ETX?
MAXIM INTEGRATED / ANALOG DEVICES
