MEAN WELL DDR15L24 Industrial DIN Rail Power Module
The DDR15L24 series is a 15W DIN Rail mountable DC-DC converter designed for industrial applications. Its ultra-slim width of 17.5mm and wide input range of 18-75V enable flexible integration into control systems, automation, and communication infrastructure. Features include -40°C to +85°C operating temperature, 4KVdc reinforced input/output isolation, and output voltage adjustable up to +10%. It provides comprehensive protections such as short circuit, overload, overvoltage, reverse polarity, and undervoltage lockout. Suitable for industrial control, telecom, and factory automation, it ensures reliable, efficient power conversion even in harsh environments.
MEAN WELL DDR15L24 Industrial DIN Rail Power Module Specifications:
- Dimensions: 17.5 x 90 x 54.5 mm (W x H x D)
- Input voltage: 18~75Vdc
- Output voltage: 24Vdc (adjustable +10%)
- Rated power: 15W
- Ripple & noise: 100mVp-p
- Efficiency: 86%
- Operating temperature: -40°C to +85°C
- Isolation voltage: 4KVdc (reinforced)
- Protection: short circuit, overload, overvoltage, reverse polarity, undervoltage lockout
- Humidity: 5% to 95% non-condensing
- MTBF: 907,000 hours minimum
- Vibration: IEC60068-2-6 compliant
- Standards: IEC 62368-1, UL508 design reference
Buy the Mean Well Series DDR-15 DC-DC Converter: DDR15L24
Experience reliable power conversion with the DDR15L24 series. Designed for industrial systems, it features a wide input range of 18-75V, adjustable 24V output, and high efficiency up to 86%. Its robust construction withstands harsh environments with -40°C to +85°C temperature tolerance, reinforced isolation of 4KVdc, and comprehensive protections including overload, short circuit, and reverse polarity. Easy to install on standard DIN rails TS-35/7.5 or TS-35/15, this converter ensures optimal performance in factory automation, communication systems, and control equipment, making it a trusted choice for your industrial power needs.
Get Mean Well DDR15L24 today—built for precision, reliability, and long-lasting durability in industrial power applications.
Frequently Asked Questions
Where can I buy MEAN WELL DDR15L24?
You can click on the BUY or RFQ button to purchase DDR15L24 from an authorized MEAN WELL distributor.
How do I troubleshoot issues or seek technical support for part DDR15L24?
You can download the DDR15L24 datasheet or visit the MEAN WELL website for support.
Who is the manufacturer of DDR15L24?
MEAN WELL
