MEAN WELL LRS3512 Power Supply
The LRS-35 series is a compact 35W single-output switching power supply featuring high efficiency of up to 89%, with full range 85-264VAC input and operating temperature from -30°C to 70°C. Its low profile design of 30mm suits industrial automation, control systems, and household appliances. With protections for short circuit, overload, and overvoltage, it complies with international safety standards such as IEC/EN 60335-1 and UL62368-1. The metallic mesh case enhances heat dissipation, ensuring reliable performance and long lifespan in demanding environments.
MEAN WELL LRS3512 Power Supply Specifications:
- Input Voltage: 85~264VAC, 120~373VDC, 47~63Hz
- Output Voltages: 5V, 12V, 15V, 24V, 36V, 48V
- Rated Power: 35W (other models up to 38.4W)
- Rated Current: 7A at 5V, 3A at 12V, 2.44A at 15V, 1.5A at 24V, 1A at 36V, 0.8A at 48V
- Ripple & Noise: 80-200mVp-p depending on model
- Efficiency: up to 89%
- Operating Temperature: -30°C to 70°C
- Dimensions: approximately 99 x 92.5 x 30 mm
- Protection: Short circuit, overload, overvoltage
- Safety Standards: IEC/EN 60335-1, UL62368-1, BS EN/EN61558-1/-2-16
- Vibration Resistance: 5G
- Altitude: Up to 5000 meters
- MTBF: 3201.5K hours
Buy the Buy Mean Well LRS-35 Series Part Number LRS3512 Online
Get your hands on the high-efficiency 35W power supply from Mean Well’s LRS-35 series. Designed with full range input, protections, and a compact 30mm low profile, it is ideal for industrial automation, control systems, and household appliances. The advanced metallic mesh case improves heat dissipation, supporting operation from -30°C to 70°C without fans. With certifications for safety and EMC compliance, this durable power supply guarantees long-term reliability, making it the perfect choice for diverse applications requiring dependable, stable power.
Order your Mean Well LRS-35 series 12V power supply today and ensure reliable power for your industrial and household devices.
Frequently Asked Questions
Where can I buy MEAN WELL LRS3512?
You can click on the BUY or RFQ button to purchase LRS3512 from an authorized MEAN WELL distributor.
How do I troubleshoot issues or seek technical support for part LRS3512?
You can download the LRS3512 datasheet or visit the MEAN WELL website for support.
Who is the manufacturer of LRS3512?
MEAN WELL
