MOLEX 1053101110 Nano-Fit Power Connector
The MOLEX 105310-1110 Nano-Fit Power Connector is a versatile vertical header ideal for power distribution in wire-to-board applications. Its compact Nano-Fit design minimizes space requirements while maintaining high-current carrying capacity (up to 7.5A per contact). Constructed with a brass body, tin plating for both mating and termination interfaces, and a liquid crystal polymer resin, this connector ensures durability and reliable electrical connection. It is polarized to both the mating part and the PCB, enhancing assembly accuracy and preventing mis-matches. The connector is suitable for applications requiring a robust and space-efficient power connection, such as consumer electronics, industrial equipment, and automotive systems.
MOLEX 1053101110 Nano-Fit Power Connector Specifications:
- Product Family: PCB Headers
- Series: 105310
- Application: Power, Wire-to-Board
- Circuits (Loaded): 10 Circuits (maximum)
- Color: Black
- Durability (mating cycles max): 25
- Flammability: 94V-0
- Glow-Wire Capable: Yes
- Guide to Mating Part: Yes
- Lock to Mating Part: Yes
- Material - Metal: Brass
- Material - Plating Mating: Tin
- Material - Plating Termination: Tin
- Material - Resin: Liquid Crystal Polymer
- Number of Rows: 2
- Orientation: Vertical
- PC Tail Length: 3.20mm
- PCB Locator: Yes
- PCB Retention: Yes
- PCB Thickness - Recommended: 1.60mm, 2.40mm
- Pitch - Mating Interface: 2.50mm
- Pitch - Termination Interface: 2.50mm
- Plating min - Mating: 1.524µm
- Plating min - Termination: 1.524µm
- Polarized to Mating Part: Yes
- Polarized to PCB: Yes
- Current - Maximum per Contact: 7.5A
- Voltage - Maximum: 250V AC (RMS)/DC
- Operating Temperature Range: -40° to +105°C
- Mates With: Nano-Fit Receptacle Housing 1053081210
