MOLEX 10897200 C-Grid Header
This is a 2.54mm pitch C-Grid breakaway header with dual row, vertical orientation. Designed for high temperature applications, it features 20 circuits, 0.76um gold selective plating, and tin PC tail plating. Suitable for board-to-board and wire-to-board connections, it offers durability up to a maximum of 1000 mating cycles, operates within -40°C to +105°C, and complies with RoHS, REACH, and UL standards. Constructed from high-temperature thermoplastic with a copper alloy metal core, it provides reliable electrical performance with maximum current of 3A and voltage of 250V.
MOLEX 10897200 C-Grid Header Specifications:
- Pitch: 2.54mm
- Number of Circuits: 20
- Color - Resin: High Temperature Thermoplastic
- Material - Metal: Copper Alloy
- Material - Plating Mating: Gold
- Material - Plating Termination: Tin
- Material - Resin: High Temperature Thermoplastic
- Durability: 1000 mating cycles max
- Operating Temperature Range: -40°C to +105°C
- Voltage Rating: 250V
- Current per Contact: 3A
- Net Weight: 1.196g
- PC Tail Length: 2.79mm
- PCB Thickness - Recommended: 1.60mm
- Packaging Type: Bag
- Orientation: Vertical
- Guide to Mating Part: None
- Polarized to Mating Part: No
- Shrouded: No
- Stackable: No
Buy the Molex 10897200 – Reliable C-Grid Breakaway Header for Industrial Applications
Discover the reliable Molex C-Grid Header designed for durable industrial applications. Featuring a 2.54mm pitch, dual row configuration, and high temperature resistance, this connector ensures stable board-to-board and wire-to-board connections. With gold-plated contacts, a robust thermoplastic body, and a maximum of 1000 mating cycles, it is ideal for demanding environments. Order online today to benefit from fast delivery, quality assurance, and seamless integration into your electronic projects, ensuring long-term performance and safety.
Order your Molex Series 70280 10897200 today and ensure your industrial connections are built with dependable, high-quality headers designed for durability and performance.
Frequently Asked Questions
Where can I buy MOLEX 10897200?
You can click on the BUY or RFQ button to purchase 10897200 from an authorized MOLEX distributor.
How do I troubleshoot issues or seek technical support for part 10897200?
You can download the 10897200 datasheet or visit the MOLEX website for support.
Who is the manufacturer of 10897200?
MOLEX
