MOLEX 191150014 Avikrimp Snap Spade Terminal
The MOLEX 19115-0014 Avikrimp Snap Spade Terminal is a solderless termination solution for 18-22 AWG wire. It's designed with a closed barrel and tin plating for optimal conductivity and corrosion resistance. The nylon insulation provides excellent electrical and mechanical protection. Commonly used in automotive, industrial equipment, and consumer electronics, this terminal ensures a secure and reliable connection. Its compact design and ease of use make it a preferred choice for various wire termination applications.
MOLEX 191150014 Avikrimp Snap Spade Terminal Specifications:
- Status: Active
- Overview: Solderless Terminals
- Description: Avikrimp Snap Spade Terminal for 18-22 AWG Wire
- Product Family: Ring and Spade Terminals
- Crimp Quality Equipment: Yes
- Mil-Spec: N/A
- Product Name: Avikrimp
- Type: Spade Snap
- Barrel Type: Closed
- Flammability: 94V-2
- Insulation: Nylon (PA)
- Material - Plating Mating: Tin
- Net Weight: 0.858/g
- Packaging Type: Bag
- Plating min - Mating: 4.064µm
- Plating min - Termination: 4.064µm
- Stud Size: 10 (M5)
- Wire Insulation Diameter: 3.60mm max.
- Wire Size AWG: 18, 20, 22
- Lead-freeProcess Capability: N/A
- Engineering Number: AA-8715-10
- EU ELV: Not Relevant
- EU RoHS: Compliant
- REACH SVHC: Not Contained
- Halogen-Free Status: Low-Halogen
- RoHS Phthalates: Not Contained
- Application Tooling PremiumGrade Hand Crimp Tool: 640010100
- Application Tooling Crimp Head for AT-200 Pneumatic Hand Tool: 640050100
