MOLEX 194300003 Wire Connector
This splicing connector by Molex is designed for quick, secure connections of 12-22 AWG wires. Featuring a yellow insert for easy identification, it operates safely up to 1000V and withstands temperatures from -30°C to +105°C. Made from brass with a non-plated finish, it provides reliable electrical performance in lighting and signage applications. The connector’s compact design ensures easy installation and secure holding for multiple wire sizes. Suitable for various industrial wiring needs, it adheres to RoHS and UL standards, ensuring safety and environmental compliance.
MOLEX 194300003 Wire Connector Specifications:
- Voltage - Maximum: 1000V
- Temperature Range - Operating: -30°C to +105°C
- Wire Size AWG: 12, 14, 16, 18, 20, 22
- Wire Insulation Diameter: 3.30mm
- Material - Metal: Brass
- Color - Resin: Yellow
- Flammability: 94V-2
- Net Weight: 2.881 grams per unit
- Packaging Type: Bag
- Insulation: None
- Barrel Type: Closed
- Agency Certification: UL
- RoHS Compliance: Yes
- Halogen-Free: Yes
- Low-Halogen: Yes
- Reference Drawing: SD-19430-001
Buy the Buy Molex Splices Part Number 0194300003 Online
Secure your electrical wiring with the Molex series19430 push-in wire connector, designed for 12-22 AWG wires. Rated up to 1000V and capable of operating between -30°C to +105°C, it ensures safe, reliable connections in lighting and signage applications. Its compact design simplifies installation, providing a secure hold for multiple wire sizes. Made from durable brass with a yellow resin insert, this connector adheres to RoHS and UL standards for safety and environmental responsibility. Ideal for industrial or commercial wiring projects, order online now for quick delivery.
Order your Molex Series19430 0194300003 push-in wire connector today and ensure reliable, secure connections for your lighting or signage projects.
