MOLEX 2002411113 Mega-Fit Vertical Header
The MOLEX 200241-1113 Mega-Fit Vertical Header is a robust connector solution for wire-to-board applications. Designed with a 5.70mm pitch and 3 circuits, it provides a secure and reliable connection. The matte tin plating ensures excellent solderability and corrosion resistance. Constructed with a high conductivity copper base and liquid crystal polymer resin, this header offers durability and performance in demanding environments. It is ideal for power applications requiring high current capacity and is compatible with Mega-Fit receptacle housings.
MOLEX 2002411113 Mega-Fit Vertical Header Specifications:
- Application: Power, Wire-to-Board
- Breakaway Circuits (Loaded): No
- Circuits (maximum): 3
- Color - Resin: Black
- Current-Max-Numeric: 23.5
- Datasheet Order No: 987650-5401
- Durability (mating cycles max): 20
- First Mate / Last Break: No
- Glow-Wire Capable: Yes
- Guide to Mating Part: No
- Keying to Mating Part: None
- Lock to Mating Part: Yes
- Material - Metal: High Conductivity Copper
- Material - Plating: Matte Tin
- Material - Resin: Liquid Crystal Polymer
- Mating Material - Plating: Matte Tin
- Net Weight: 2.120/g
- Number of Rows: 1
- Orientation: Vertical
- PCB Locator: Yes
- PCB Retention: Yes
- PCB Thickness - Recommended: 1.58mm, 2.36mm
- Pitch - Mating Interface: 5.70mm
- Pitch - Termination Interface: 5.70mm
- Plating min - Mating: 1.524µm
- Plating min - Termination: 2.540µm
- Polarized to Mating Part: Yes
- Polarized to PCB: Yes
- Temperature Range - Operating: -40° to +105°C, -40° to +120°C
- Termination Interface: Through Hole
- Voltage - Maximum: 600V AC (RMS)/DC
- Mates With: Mega-Fit Receptacle Housing 200456
Buy the 200241-1113 MOLEX Mega-Fit Vertical Header | myMectronic
Purchase the MOLEX 200241-1113 Mega-Fit Vertical Header securely and reliably online.
Buy Now
Frequently Asked Questions
Where can I buy MOLEX 2002411113?
You can click on the BUY or RFQ button to purchase 2002411113 from an authorized MOLEX distributor.
How do I troubleshoot issues or seek technical support for part 2002411113?
You can download the 2002411113 datasheet or visit the MOLEX website for support.
Who is the manufacturer of 2002411113?
MOLEX
