MOLEX 2049270301 Board-to-Board Connector
The SlimStack Board-to-Board Receptacle offers a compact, reliable connection solution for electronic assemblies with a 0.40mm pitch, matching SlimStack plug connectors. Designed with a floating FSB3 series interface, it features three circuits with a mated height of 3.20mm and width of 3.00mm, suitable for space-constrained applications. Made from durable copper alloy and liquid crystal polymer, it supports up to 0.3A current at 40V, ensuring robust performance in various environments. Its surface-mount design simplifies assembly and maintenance in high-density electronic systems.
MOLEX 2049270301 Board-to-Board Connector Specifications:
- Pitch - Mating Interface: 0.40mm
- Mated Height: 3.20mm
- Mated Width: 3.00mm
- Number of Circuits: 30
- Material - Metal: Copper Alloy
- Material - Plating Mating: Gold
- Material - Plating Termination: Gold
- Material - Resin: Liquid Crystal Polymer
- Durability: Up to 30 mating cycles
- Operating Temperature Range: -40°C to +125°C
- Current - Maximum per Contact: 0.3A
- Voltage - Maximum: 40V AC/DC
- Color - Resin: Not specified
- Orientation: Vertical
- Packaging: Embossed Tape on Reel
Buy the Molex Series SlimStack 0.40mm Pitch: 2049270301
Enhance your electronic assemblies with the Molex SlimStack Board-to-Board Connector. Featuring a slim 0.40mm pitch and 30 circuits, it provides a compact, high-reliability connection for space-constrained designs. Made from durable materials like copper alloy and liquid crystal polymer, it supports up to 0.3A and 40V. Easy to mount with surface mount technology, ensuring quick assembly and dependable performance in various environments. Ideal for advanced electronics requiring secure, space-efficient interconnects.
Buy Molex 2049270301 now and experience reliable high-density connections suitable for compact electronic systems.
