MOLEX 2059570771 PCB Header
The Micro-Lock Plus wire-to-board connector system features a 1.25mm pitch, single-row PCB header with potting capability, positive lock, and tin-bismuth plating. Designed for surface mount applications, it supports 7 circuits with a black color resin, offering high durability with up to 30 mating cycles. Its vertical orientation, shrouded design, and compatibility with robotic placement make it ideal for compact, reliable electronic assemblies requiring secure connections and robust performance in various operating temperatures from -40°C to +105°C.
MOLEX 2059570771 PCB Header Specifications:
- Pitch - Mating Interface: 1.25mm
- Number of Circuits: 7
- Color - Resin: Black
- Material - Metal: Brass
- Material - Plating Mating: Tin-Bismuth
- Material - Plating Termination: Tin-Bismuth
- Material - Resin: Polyamide
- Durability (mating cycles max): 30
- Maximum Current per Contact: 3.6A
- Maximum Voltage: 50V AC/DC
- Operating Temperature Range: -40°C to +105°C
- Orientation: Vertical
- Packaging: Embossed Tape on Reel
- Surface Mount Compatible: Yes
- Glow-Wire Capable: No
- Robotic Placement: Fully
- Stackable: No
- Shrouded: Yes
- Polarity / Keying: None
- Net Weight: 300.410 mg
Buy the Molex Series Micro-Lock Plus PCB Header: 2059570771
Order Molex 2059570771 online today to secure high-quality, reliable connections for your electronic projects. This 1.25mm pitch PCB header supports 7 circuits, features a positive lock, and is designed for surface mount assembly. Its robust construction using brass with tin-bismuth plating ensures durability and excellent electrical performance, while its vertical orientation and shrouded design facilitate easy robotic placement. Perfect for compact, high-reliability applications operating from -40°C to +105°C, this connector guarantees secure, long-term connections in demanding environments.
Get Molex 2059570771 today—built for precision and long-lasting durability in electronic connections.
Frequently Asked Questions
Where can I buy MOLEX 2059570771?
You can click on the BUY or RFQ button to purchase 2059570771 from an authorized MOLEX distributor.
How do I troubleshoot issues or seek technical support for part 2059570771?
You can download the 2059570771 datasheet or visit the MOLEX website for support.
Who is the manufacturer of 2059570771?
MOLEX
