MOLEX 2153232041 Mini-Fit Jr. Cable Assembly
The MOLEX 215323-2041 is a Mini-Fit Jr. male-to-pigtail cable assembly designed for power applications in wire-to-wire configurations. It boasts a single-row design, a black nylon resin housing, and gold-plated mating contacts for enhanced conductivity and corrosion resistance. This assembly is ideal for applications requiring a secure and reliable power connection, such as in automotive, industrial equipment, and consumer electronics.
MOLEX 2153232041 Mini-Fit Jr. Cable Assembly Specifications:
- overview: Mini-Fit Family Power Connectors
- application: Power, Wire-to-Wire Assembly
- configuration: Single Ended
- connector_type: Mini-Fit Jr.-to-Pigtail
- cable_length: 150.00mm
- circuits_loaded: 4
- color: Black (Resin)
- gender: Male-Pigtail
- material_metal: Brass
- plating_mating: Gold (Au)
- plating_termination: Tin
- material_resin: Nylon
- net_weight: 16.995/g
- number_of_rows: 1
- pitch_mating_interface: 4.20mm
- plating_min_mating: 0.762µm
- plating_min_termination: 2.032µm
- wire_insulation_diameter: 1.80-3.10mm
- wire_size_awg: 16
- wire_cable_type: UL 1015
- current_max_per_contact: 9.0A
- voltage_max: 600V
- upc: 193264597758
- material_info: Not Contained Per - D(2020)4578-DC
- halogen_free_status: Not Low-Halogen
- mates_with: Mini-Fit Jr. Receptacle Housing 5557, Mini-Fit TPA2 Cable Assembly 145135
- sales_drawing: 2153232041-000
