MOLEX 2157603006 Micro-Fit+ Header
The MOLEX 215760-3006 is a Micro-Fit+ right-angle header within the 215760 series. This connector is designed for secure wire-to-board connections and is characterized by its right-angle orientation, 3.00mm pitch, and 6 circuit configuration. The gold plating ensures excellent conductivity and durability, while the UL 94V-0 flame retardant resin provides enhanced safety. It's commonly used in various industrial and consumer electronics applications where a compact and reliable connection is required.
MOLEX 2157603006 Micro-Fit+ Header Specifications:
- Pitch - Mating Interface: 3.00mm
- Pitch - Termination Interface: 3.00mm
- Plating min - Mating: 0.762µm
- Material - Metal: Copper Alloy
- Material - Plating: Gold
- Material - Resin: Liquid Crystal Polymer
- Durability (mating cycles max): 200
- Current - Maximum per Contact: 12.5A
- Voltage - Maximum: 600V AC (RMS)/DC
- PCB Thickness - Recommended: 1.57mm
- PC Tail Length: 3.18mm
- Number of Rows: 1
- Orientation: Right Angle
- Temperature Range - Operating: -40° to +105°C
- Termination Interface: Style: Through Hole
- Circuits (maximum): 6
- Color - Resin: Black
- Net Weight: 1.054/g
Buy the 215760-3006 MOLEX Micro-Fit+ Header | myMectronic
Purchase the MOLEX 215760-3006 Micro-Fit+ Header securely and reliably online.
Buy Now
Frequently Asked Questions
Where can I buy MOLEX 2157603006?
You can click on the BUY or RFQ button to purchase 2157603006 from an authorized MOLEX distributor.
How do I troubleshoot issues or seek technical support for part 2157603006?
You can download the 2157603006 datasheet or visit the MOLEX website for support.
Who is the manufacturer of 2157603006?
MOLEX
