MOLEX 2153232042 Mini-Fit Jr. Cable Assembly
The MOLEX 215323-2042 is a Mini-Fit Jr. male-to-pigtail cable assembly designed for power applications in wire-to-wire connections. It boasts a single-row configuration, a black resin housing, and robust materials like brass and nylon. With a maximum current rating of 9.0A and a maximum voltage of 600V, this assembly provides a secure and efficient power connection for various industrial and commercial applications. It is RoHS compliant and REACH SVHC substances are not contained.
MOLEX 2153232042 Mini-Fit Jr. Cable Assembly Specifications:
- overview: Mini-Fit Family Power Connectors
- application: Power, Wire-to-Wire Assembly
- configuration: Single Ended
- connector_type: Mini-Fit Jr.-to-Pigtail
- cable_length: 300.00mm
- circuits_loaded: 4
- color: Black (Resin)
- gender: Male-Pigtail
- material_metal: Brass
- material_plating_mating: Gold (Au)
- material_plating_termination: Tin
- material_resin: Nylon
- net_weight: 29.734/g
- number_of_rows: 1
- packaging_type: Bag
- pitch_mating_interface: 4.20mm
- plating_min_mating: 0.762µm
- plating_min_termination: 2.032µm
- wire_insulation_diameter: 1.80-3.10mm
- wire_size_awg: 16
- wire_cable_type: UL 1015
- current_maximum_per_contact: 9.0A
- voltage_maximum: 600V
- upc: 193264597765
- material_info: RoHS Compliant, REACH SVHC Not Contained
