MOLEX 22566107 SL Crimp Housing
The MOLEX 22-56-6107 is a versatile SL crimp housing designed for signal transmission in wire-to-board applications. It's part of the 70450 series and offers a 2.54mm pitch, accommodating a range of wire gauges. The housing's dual-row, 10-circuit configuration makes it suitable for applications requiring multiple connections. Constructed from durable black polyester, it provides reliable insulation and mechanical protection. Its RoHS compliance and operating temperature range of -40°C to +105°C ensure suitability for a wide range of industrial environments. This housing is designed to mate with 2.54mm pitch C-Grid Headers, providing a secure and efficient connection.
MOLEX 22566107 SL Crimp Housing Specifications:
- status: Active
- overview: SL Modular Connectors
- description: 2.54mm Pitch SL Crimp Housing, Dual Row, Version F, 10 Circuits, Black
- product_family: Crimp Housings
- series: 70450
- application: Signal, Wire-to-Board
- comments: Version F, Version F
- upc: 800754397926
- breakaway: No
- circuits_maximum: 10
- color_resin: Black
- flammability: 94V-0
- gender: Receptacle
- glow_wire_capable: No
- material_resin: Polyester
- net_weight_g: 0.960
- number_of_rows: 2
- packaging_type: Bag
- panel_mount: No
- pitch_mating_interface: 2.54mm
- stackable: No
- temperature_range_operating_c: -40° to +105°
- lead_free_process_capability: N/A
- engineering_number: 704500253
- product_specification: TS-70541-001-001
- sales_drawing: SD-70450-0250-0275
- eu_elv: Not Relevant
- eu_rohs: Compliant
- reach_svhc: Not Contained
- halogen_free_status: Not Low-Halogen
- rohs_phalates: Not Contained
- mates_with: 2.54mm Pitch C-Grid Header 70229, 70280, 70246, 70247
- uses_with: 70058, 71851
