MOLEX 26602120 PCB Header
This product is a KK 396 Header from Molex, designed for PCB and board-to-board applications. It features a vertical orientation, 12 circuits, and is tin-plated for reliable electrical connection. Made from durable brass and polyester resin, it supports up to 7.0A current and 250V voltage. The header is compliant with RoHS and CSA, UL certified, with a maximum operating temperature of 235°C. It is suitable for various electronic assemblies requiring robust, solderless connections and has a slim profile with 3.96mm pitch.
MOLEX 26602120 PCB Header Specifications:
- Circuits: 12
- Orientation: Vertical
- Color - Resin: Natural
- Material - Metal: Brass
- Material - Plating Mating: Tin
- Material - Plating Termination: Tin
- Material - Resin: Polyester
- Net Weight: 3.276 grams
- Color: Natural
- Durability: Up to 25 mating cycles
- Flammability: 94V-0
- Maximum Operating Temperature: 235°C
- Current - Max per Contact: 7.0A
- Voltage - Max: 250V
- Pitch - Mating Interface: 3.96mm
- PC Tail Length: 3.56mm
- Ingress Protection: None
- PCB Thickness - Recommended: 1.60mm
- Packaging Type: Bag
- RoHS: Compliant
- UL: Yes
- CSA: Yes
Buy the Buy Molex KK 396 Header Part Number 0026602120 Online
Get the Molex KK 396 Header with 12 circuits, vertical orientation, and tin-plated contacts, perfect for PCB and board-to-board connections. Made from durable brass and polyester resin, it operates at temperatures up to 235°C and supports 7.0A and 250V. RoHS compliant and certified by UL and CSA, this high-quality connector provides reliable electrical connections, ensuring your electronic assemblies are secure and efficient. Conveniently available online for quick and easy procurement to enhance your project reliability.
Order your Molex KK 396 Header PartNumber 0026602120 today and equip your electronic projects with reliable, durable PCB connections.
Frequently Asked Questions
Where can I buy MOLEX 26602120?
You can click on the BUY or RFQ button to purchase 26602120 from an authorized MOLEX distributor.
How do I troubleshoot issues or seek technical support for part 26602120?
You can download the 26602120 datasheet or visit the MOLEX website for support.
Who is the manufacturer of 26602120?
MOLEX
