MOLEX 901310145 PCB Header
The C-Grid III Interconnects are 2.54mm pitch PCB headers designed for signal and wire-to-board applications. Featuring a dual-row, vertical orientation with 50 circuits, these headers are made from durable polyester resin with brass metal components, plated in tin for reliable terminations. They are stackable, non-shrouded, and have a maximum voltage rating of 350V, supporting operational temperatures from -55°C to +125°C. Ideal for secure and compact electrical connections in various electronic assemblies requiring high current capacity and easy integration.
MOLEX 901310145 PCB Header Specifications:
- Pitch: 2.54mm
- Number of Circuits: 50
- Material - Metal: Brass
- Material - Plating: Tin
- Material - Resin: Polyester
- Color: Black
- Orientation: Vertical
- Stackable: Yes
- Temperature Range - Operating: -55°C to +125°C
- Voltage - Maximum: 350V
- Current - Maximum per Contact: 3.0A
- Packaging: Tray
- Breakaway: Yes
- Guide to Mating Part No: None
- Lock to Mating Part: None
- PCB Locator: No
- PCB Retention: None
- First Mate / Last Break: No
- Glow-Wire Capable: No
- Shrouded: No
- Polarized to Mating Part: Yes
- Polarized to PCB: No
- Lock to Mating Part: None
Buy the Buy Molex C-Grid III Part Number 0901310145 Online
Purchase the Molex C-Grid III PCB header online for your signal and wire-to-board projects. With a 2.54mm pitch, dual-row design, 50 circuits, and tin-plated brass contacts, this stackable and reliable connector ensures secure electrical connections in compact spaces. Operating effectively from -55°C to +125°C, it supports up to 350V and 3A per contact. Conveniently packaged in trays, it is ideal for efficient assembly and high-performance electronic systems, making it the perfect choice for professionals seeking durability and precision.
Get Molex C-Grid III 0901310145 today—designed for high-density, reliable signal connections and long-lasting durability in electronic assemblies.
Frequently Asked Questions
Where can I buy MOLEX 901310145?
You can click on the BUY or RFQ button to purchase 901310145 from an authorized MOLEX distributor.
How do I troubleshoot issues or seek technical support for part 901310145?
You can download the 901310145 datasheet or visit the MOLEX website for support.
Who is the manufacturer of 901310145?
MOLEX
