MOLEX 307001060 High-Density Automotive Connector
The H-DAC 64 high-density automotive connector features a 2.54mm pitch and a 0.64mm width, designed for dual-row female harness assemblies with 6 circuits and polarization option 1 in gray color. It is suitable for automotive applications requiring high-density wire-to-board or wire-to-wire connections, with a maximum current rating of 7.0A per contact. Made from modified polystyrene, it operates within a temperature range of -40°C to +100°C, offering RoHS and ELV compliance, halogen-free construction, and easy mating with compatible headers and crimp housings for secure electrical connections.
MOLEX 307001060 High-Density Automotive Connector Specifications:
- Pitch: 2.54mm
- Width: 0.64mm
- Number of Circuits: 6
- Color: Gray
- Gender: Receptacle
- Lock to Mating Part: Yes
- Material - Resin: Modified Polystyrene
- Operating Temperature Range: -40°C to +100°C
- Current - Maximum per Contact: 7.0A
- RoHS, ELV, REACH SVHC: Compliant
- Halogen-Free: Yes
- Net Weight: 2.733/g
- Packaging Type: Bag
- Application: Power, Wire-to-Board, Wire-to-Wire
Buy the Buy Molex Automotive Connector Part Number 0307001060 Online
Experience seamless online purchasing of the Molex High-Density Automotive Connector with part number 0307001060. Designed for reliable automotive connections, it features a 2.54mm pitch, 6 circuits, and polarization option 1 in gray color. Made from durable modified polystyrene, it operates within a temperature range of -40°C to +100°C, ensuring safety and compliance with RoHS and ELV standards. Perfect for power, wire-to-wire and wire-to-board applications, this connector guarantees safety, durability, and ease of installation for automotive wiring needs.
Buy Molex 0307001060 now and experience unmatched reliability and performance for automotive wiring and electronic systems.
Frequently Asked Questions
Where can I buy MOLEX 307001060?
You can click on the BUY or RFQ button to purchase 307001060 from an authorized MOLEX distributor.
How do I troubleshoot issues or seek technical support for part 307001060?
You can download the 307001060 datasheet or visit the MOLEX website for support.
Who is the manufacturer of 307001060?
MOLEX
